Board Interfaces 43
cPCI-6965
CompactPCI J3 Pin Assignment
Table 4-16: CompactPCI J3 Connector Pin Definition
Pin Z A B C D E F
1 GND HDA_RST-L HDA_SYNC HDA_BIT_CLK HDA_SDOUT HAD_SDIN0 GND
2 GND HAD_SDIN1 HAD_SDIN2 HAD_SDIN3 NC NC GND
3 GND PS2-KBD PS2-KBC NC PS2-MSD PS2-MSC GND
4 GND SATA-T2P SATA-T2N GND NC NC GND
5 GND GND GND NC GND GND GND
6 GND SATA-R2P SATA-R2N GND NC NC GND
7 GND NC NC NC I2C_CLK I2C_DAT GND
8 GND NC NC NC NC NC GND
9 GND NC NC RGB-BLUE RGB-RED RGB-GREEN GND
10 GND USB-OC# RGB-DDCCLK RGB-DDCDAT RGB-HSYNC RGB-VSYNC GND
11 GND USB-P8 USB-N8 GND USB-P9 USB-N9 GND
12 GND USB-P6 USB-N6 GND USB-P7 USB-N7 GND
13 GND NC NC GND USB-P5 USB-N5 GND
14 GND NC USB-OC5# USB-OC6# USB-OC7# USB-OC8# GND
15 GND NC NC GND NC NC GND
16 GND NC NC GND NC NC GND
17 GND NC NC GND NC NC GND
18 GND NC NC GND NC NC GND
19 GND +5V +5V +12V +5V +5V GND
PS/2 Keyboard/Mouse
Serial ATA
RGB
I2C
USB port
High Definition Audio
