14 Specifications
Power Consumption
The following tables provide information on the power consump-
tion of the cPCI-6965 Series when using the Intel® Core 2 Duo
T7500 or Celeron 550 processor with 2x 2GB SO-DIMM and
onboard 60GB SATA hard drive. The systems were tested in Idle
Mode and Full Loading Mode under Windows XP. The cPCI-6965
is powered by single 5V power rail.
Table 2-5: Intel® Core™2 Duo T7500 Power Consumption
Table 2-6: Intel® Celeron® 550 Power Consumption
Intel® Core™2 Duo T7500
OS/Mode Current 5V Total Power
DOS/Idle mode 5.712 A 28.56 W
Linux/Idle mode 3.411 A 17.055 W
Windows XP/
Idle mode
3.490 A 17.45 W
Windows® XP/
CPU 100% Usage
9.416 A 47.08 W
Intel® Celeron® 550
OS/Mode Current 5V Total Power
DOS/Idle mode 5.860 A 27.93 W
Linux/Idle mode 4.200 A 21.00 W
Windows XP/
Idle mode
4.278 A 21.39 W
Windows® XP/
CPU 100% Usage
6.534 A 32.67 W
