Specifications
11
cPCI-6965
2.3
I/O Connectivity Table
SBC
Table 2-1: SBC I/O Connectivity
1. One 7-pin connector for external HDD and one connector for
onboard 2.5” HDD.
Function
cPCI-6965
cPCI-6965D
Faceplate
Board
Faceplate
Board
GbE
Y x2
--
Y x2
--
COM
Y (DB-9)
Y x2 (DB-9)
USB
Y x4
--
Y x4
--
PMC
--
--
--
Y
DVI
Y x2
--
Y x2
--
SATA
1
--
Y x2
Y x2
CF
--
Y
--
Y
PS/2 KB/MS
--
--
Y
--
Parallel
Y
USB Flash
Y (optional)
Y (optional)
LEDs
Y x4
--
Y x4
--
Reset Button
Y
--
Y
--
