40 Board Interfaces
Table 4-13: PMC Connector Pin Definition
34 GND NC
35 GND TRDY#
36 IRDY# +3.3V
37 DEVSEL# GND
38 +5V STOP#
39 PCIXCAP PERR#
40 LOCK-L GND
41 NC +3.3V
42 NC SERR#
43 PAR CBE1#
44 GND GND
45 VIO AD14
46 AD15 AD13
47 AD12 M66EN
48 AD11 AD10
49 AD9 AD8
50 +5V +3.3V
51 GND AD7
52 CBE0# NC
53 AD6 +3.3
54 AD5 NC
55 AD4 NC
56 GND GND
57 VIO NC
58 AD3 NC
59 AD2 GND
60 AD1 NC
61 AD0 ACK64#
62 +5V +3.3V
63 GND GND
64 REQ64# NC
Pin# Upper1 Signal Upper2 Signal
