Specifications 7
cPCI-6965
2 Specifications
2.1 cPCI-6965 SBC Specifications
CompactPCI
Standard
PICMG® 2.0 CompactPCI® Rev. 3.0
PICMG® 2.1 Hot Swap specification Rev.2.0
Mechanical
Standard 6U CompactPCI®
Board size: 233.23 mm x 160mm
Single-slot (4HP, 20.32mm) or dual-slot (8HP, 40.64mm)
width
CompactPCI® connectors with J1, J2, J4, J5 for
cPCI-6965, cPCI-6965D
CompactPCI® connectors with J1, J2 for cPCI-6965DZ
Processor
µFC-PGA Intel® Core™2 Duo 2.2GHz (T7500),
4MB L2 cache, FSB 800MHz
µFC-PGA Intel® Celeron® 2.0GHz (550), 1MB L2 cache,
FSB 533MHz
Passive heatsink
Chipset
IIntel GME965 Memory Controller Hub (MCH)
Intel ICH8M I/O Controller Hub (ICH)
Memory
Dual channel DDR2-667 un-buffer non-ECC memory
Two SO-DIMM sockets (stacked type)
Maximum 4GB capacity
CompactPCI Bus
PCI 32bit/ 33MHz; 3.3V, 5V universal V(I/O)
Supports operation in system slot only
PMC One PCI 32bit/ 33MHz PMC, 3.3V, 5V universal V(I/O)
Ethernet
Two PCI-Express x1 Intel® 82573L GbE controllers
Two egress 10/100/1000BASE-T ports
Graphics
GMA X3100 integrated in GME965 GMCH
Shared system memory up to 384 MB
Two DVI ports on front panel: one DVI-I (digital + analog),
one DVI-D (digital only)
Analog signal with up to 32-bit, 2048x1536 resolution @75Hz
Serial Ports
Up to two 16C550 compatible DB-9 serial ports from
Super I/O IT8712F
Both ports support RS232/422/485/485+ by switch
selection
