Acrosser ACE-MINI - Manual (Page 74)

Revision: 1.0
74
4
LAMP2 Control.
1 = Light in Sourcing Mode; Dark
in Sinking Mode,
0 = Dark in Sourcing Mode; Light
in Sinking Mode
Yes Yes 0
5
LAMP3 Control.
1 = Light in Sourcing Mode; Dark
in Sinking Mode,
0 = Dark in Sourcing Mode; Light
in Sinking Mode
Yes Yes 0
6
LAMP4 Control.
1 = Light in Sourcing Mode; Dark
in Sinking Mode,
0 = Dark in Sourcing Mode; Light
in Sinking Mode
Yes Yes 0
7
Reel running mode
0 =Stop Mode, 1=Running Mode
Yes No 0
REEL E Timing Steps Register (C4h & C5h)
Bit Field Description
Software
Readable
Software
Writable
Value
after
Reset
0 - 15 Yes Yes 0
REEL E Running Steps Register (C6h & C7h)
Bit Field Description
Software
Readable
Software
Writable
Value
after
Reset
0 - 15 Yes Yes 0
