Features:
Mini-ITX chassis with PCI Gaming I/O card.
Is suitable for any Mini-ITX motherboard with PCI slot.
Standard 8-liner 72-pin plus 10-pin interface.
30 Digital Inputs, 27 digital outputs, 512KB NVRAM , 4 x 16-bittimers.
Chassis intrusion switch.
3 x Serial ports, Intrusion logger, Real Time Clock, Software protection (
AR-B2019A
).
Description
Mini ITX Chassis with Gaming Control Card
Dimension
Depth: 266.2 * 245.5 * 134.5mm.
System Thermal One system fan.
CPU Board
Standard Mini-ITX motherboard with PCI slot.
Storage
One 2.5” HDD bay.
Chassis Intrusion
Switch
One chassis intrusion switch.
Front Panel
1. Standard Mini-ITX bracket opening.
2. 1 x PCI card bracket.
3. D-sub 9 connector opening.
4. Power LED.
5. ATX power switch.
Gaming I/O
1. 8-liner interface.
2. 30 x 5KV optical isolated digital inputs.
3. 24 x 500mA MOSFET outputs.
4. 2 x 1000mA output for tower lamps.
5. One 180 degrees 8-bit readable DIP switch.
6. Four 16-bit timers with timeout interrupt.
7. 256KB or dual 512KB SRAM with battery backup.
8. Optional advanced version (AR-B2019A).
a. 3 serial ports (RS-232C, TTL, ccTalk).
SAS bit-9 protocol support.
b. Intrusion
logger.
c. Secured real time clock.
d. Software security: ProtectU(programmable ID) & Dallas iButton
socket.
e. Reel mechanism controller, support up to 6 reels
(ACE-MINI5495R).
Software
development kit
1. Supports Windows XP, XP embedded and Linux.
2. Device drivers.
3. Application Program Interface (API).
Power Supply
180 or 100 Watts ATX power supply.
