Acrosser ACE-MINI - Manual (Page 45)

Revision: 1.0
45
4
Port E Interrupt Enable bit. ‘0’ = No support
Interrupt from Port E as Input; ‘1’ = Support
Interrupt from Port E as Input.
Yes Yes 0
5
Port F Interrupt Enable bit. ‘0’ = No support
Interrupt from Port F as Input; ‘1’ = Support
Interrupt from Port F as Input.
Yes Yes 0
6
Port G Interrupt Enable bit. ‘0’ = No support
Interrupt from Port G as Input; ‘1’ = Support
Interrupt from Port G as Input.
Yes Yes 0
7
Port H Interrupt Enable bit. ‘0’ = No support
Interrupt from Port H as Input; ‘1’ = Support
Interrupt from Port H as Input.
Yes Yes 0
8
Port I Interrupt Enable bit. ‘0’ = No support
Interrupt from Port I as Input; ‘1’ = Support
Interrupt from Port I as Input.
Yes Yes 0
9
Port J Interrupt Enable bit. ‘0’ = No support
Interrupt from Port J as Input; ‘1’ = Support
Interrupt from Port J as Input.
Yes Yes 0
10
Port K Interrupt Enable bit. ‘0’ = No support
Interrupt from Port K as Input; ‘1’ = Support
Interrupt from Port J as Input.
Yes Yes 0
11
Port L Interrupt Enable bit. ‘0’ = No support
Interrupt from Port L as Input; ‘1’ = Support
Interrupt from Port J as Input.
Yes Yes 0
12
Timer-A Enable bit. ‘0’ = Timer-A disable; ‘1’ =
Timer-A Enable.
Yes Yes 0
13
Timer-B Enable bit. ‘0’ = Timer-B disable; ‘1’ =
Timer-B Enable.
Yes Yes 0
14
Timer-C Enable bit. ‘0’ = Timer-C disable; ‘1’ =
Timer-C Enable.
Yes Yes 0
15
Timer-D Enable bit. ‘0’ = Timer-D disable; ‘1’ =
Timer-D Enable.
Yes Yes 0
16
Port XA Interrupt Enable bit. ‘0’ = No support
Interrupt from Port XA as Input; ‘1’ = Support
Interrupt from Port XA as Input.
Yes Yes 0
17
Port XB Interrupt Enable bit. ‘0’ = No support
Interrupt from Port XB as Input; ‘1’ = Support
Interrupt from Port XB as Input.
Yes Yes 0
18~23 Reserved
Note: ACE-B2019 AGC supports I/O ports from port A to port J, it does not supports reel
control function.
