Acrosser ACE-MINI User Manual
Page 59
Revision: 1.0
59
REEL Enable Register (71h)
Bit Field
Description
Software
Readable
Software
Writable
Value
after
Reset
0
REEL A Enable bit. 0 = REEL A
Disable, 1 = REEL A Enable
Yes Yes
0
1
REEL B Enable bit. 0 = REEL B
Disable, 1 = REEL B Enable
Yes Yes
0
2
REEL C Enable bit. 0 = REEL C
Disable, 1 = REEL C Enable
Yes Yes
0
3
REEL D Enable bit. 0 = REEL D
Disable, 1 = REEL D Enable
Yes Yes
0
4
REEL E Enable bit. 0 = REEL E
Disable, 1 = REEL E Enable
Yes Yes
0
5
REEL F Enable bit. 0 = REEL F
Disable, 1 = REEL F Enable
Yes Yes
0
6 Reserved
7 Reserved
REEL Interrupt Register (72h)
Bit Field
Description
Software
Readable
Software
Writable
Value
after
Reset
0
Interrupt Status in REEL A. 0 =
No Interrupt, 1 = Interrupt active
Yes No
0
1
Interrupt Status in REEL B. 0 =
No Interrupt, 1 = Interrupt active
Yes No
0
2
Interrupt Status in REEL C. 0 =
No Interrupt, 1 = Interrupt active
Yes No
0
3
Interrupt Status in REEL D. 0 =
No Interrupt, 1 = Interrupt active
Yes No
0
4
Interrupt Status in REEL E. 0 =
Yes No
0
