Acrosser ACE-MINI - Manual (Page 104)

Revision: 1.0
104
Table 4.3.1:
.
Reel Motor Connector Pin Assignment (REEL2)
PIN Name Function Description No Pin Type PIN Name Function Description No Pin Type
A_ORL_COM
REEL A Outer Row Lamp
Common
1 HCO B_ORL_COM
REEL B Outer Row Lamp
Common
21 HCO
A_IRL_COM
REEL A Inner Row Lamp
Common
2 HCO B_IRL_COM
REEL B Inner Row Lamp
Common
22 HCO
A_BL REEL A Bottom Lamp 3 HCO B_BL REEL B Bottom Lamp 23 HCO
A_ML REEL A Middle Lamp 4 HCO B_ML REEL B B Middle Lamp 24 HCO
A_TL REEL A Top Lamp 5 HCO B_TL REEL B Top Lamp 25 HCO
N.C Reserve 6 N.C Reserve 26
N.C Reserve 7 N.C Reserve 27
A_FeedBack1 REEL A sensor feedback pin 8 DI B_FeedBack1 REEL B sensor feedback pin 28 DI
A_MPOWER +5V 9 Power B_MPOWER +5V 29 Power
A-GND Ground 10 Power B-GND Ground 30 Power
A_PAP REEL A driver A+ 11 HCO-AEP B_PAP REEL B driver A+ 31 HCO-AEP
A_PAN REEL A driver A- 12 HCO-AEP B_PAN REEL B driver A- 32 HCO-AEP
A_MPOWER REEL A Power +12V 13 Power B_MPOWER REEL B Power +12V 33 Power
A_MPOWER REEL A Power +12V 14 Power B_MPOWER REEL B Power +12V 34 Power
A_PBP REEL A driver B+ 15 HCO-AEP B_PBP REEL B driver B+ 35 HCO-AEP
A_PBN REEL A driver B- 16 HCO-AEP B_PBN REEL B driver B- 36 HCO-AEP
N.C Reserve 17 N.C Reserve 37
N.C Reserve 18 N.C Reserve 38
N.C Reserve 19 N.C Reserve 39
N.C Reserve 20 N.C Reserve 40
