Acrosser ACE-MINI - Manual (Page 51)

Revision: 1.0
51
Port EFGH Mode (24h)
Bit Field Description
Software
Readable
Software
Writable
Value
after
Reset
0
Port E (8 bit). 0 = Input Mode, 1
= Output Mode
Yes Yes 0
1
Port F (8 bit). 0 = Input Mode, 1
= Output Mode
Yes Yes 0
2
Port G (8 bit). 0 = Input Mode, 1
= Output Mode
Yes Yes 0
3
Port H (8 bit). 0 = Input Mode, 1
= Output Mode
Yes Yes 0
7 : 3 Reserved Yes No 0
Port E Data (28h)
Bit Field Description
Software
Readable
Software
Writable
Value
after
Reset
0 Bit 1 of Port E Yes
Yes (only
in Output
Mode)
0 / 1
1
Bit 2 of Port E
Yes
Yes (only
in Output
Mode)
0 / 1
2
Bit 3 of Port E
Yes
Yes (only
in Output
Mode)
0 / 1
3
Bit 4 of Port E Yes Yes (only
in Output
Mode)
0 / 1
4
Bit 5 of Port E Yes Yes (only
in Output
0 / 1
