Base Address 1 Register for I/O Accesses to Local Configuration (14h)
Bit Field Description
Software
Readable
Software Writable
Value
after
Reset
0
Memory Space Indicator. Value of 0
indicates register maps into Memory
space. Value of 1 indicates register
maps into I/O space.
Yes No 1
1 Reserved Yes No 0
6 : 2
I/O Base Address. Base address for
I/O access to local configuration
registers (default 128 bytes).
Yes No 0
31 : 7
I/O Base Address. Base address for
I/O access to local configuration
registers
Yes Yes 0
Base Address 2 Registers (18h)
Bit Field Description
Software
Readable Software
Writable
Value after
Reset
31 : 0 Not Supported Yes No 0
Base Address 3 Registers (1Ch)
Bit Field Description
Software
Readable Software
Writable
Value after
Reset
31 : 0 Not Supported Yes No 0
Base Address 4 Registers (20h)
Bit Field Description
Software
Readable Software
Writable
Value after
Reset
31 : 0 Not Supported Yes No 0
Base Address 5 Registers (24h)
Bit Field Description
Software
Readable Software
Writable
Value after
Reset
31 : 0 Not Supported Yes No 0
Cardbus CIS Pointer Registers (28h)
Bit Field Description
Software
Readable Software
Writable
Value after
Reset
31 : 0
Card bus Information Structure Pointer for PCMCIA. Not
Supported.
Yes No 0
