3xLOGIC’s VIGIL Client - Users Guide Page 26
Doc# 12031914
Audio Treeview
The Audio Treeview shows all configured and currently enabled Audio channels on the connected Server.
Double Click
Double Click on an Audio Channel to Play it Live.
Control Volume with the Windows Volume controls.
Current
Channel
The currently selected Live Audio channel.
Sensitivity
This slider adjusts the audio sensitivity without
affecting the sensitivity settings on the connected
server.
Stop Click to Stop playing the current Live Audio Channel.
This level meter indicates the audio level for the
currently selected audio channel.
Relays Treeview
The Relays Treeview shows all configured Relays on the connected Server and allows for them to be quickly
toggled on or off.
The current status of the Relay is indicated by the following icons:
The Relay is Toggled On.
The Relay is Toggled Off.
Refresh
Double Click the Refresh option to poll the current state of the
Relays from the DVR Server. Client does not actively poll for
relay state as that would be prohibative on bandwidth.
V-POS Treeview
The V-POS Treeview will be available when V-POS is installed on the DVR Server. Details of each option will be
discussed in Section 8 - V-POS Treeview Configuration.
Exceptions
Opens the POS/ATM Exceptions window, where POS/ATM
Exceptions can be created, edited, deleted, imported,
exported or manually run.
Events
Opens the POS/ATM Exception Events window, where
users can view, acknowledge, or playback POS/ATM
exception alerts.
Settings
Opens the Settings window, where V-POS settings can be
configured.
Reports
Opens the Reports window, where manual or predefined
queries can be run.
Quick Search
Opens the Quick Search window, where transactions can
be searched for by receipt number, IDX line number or
Event ID number.
