3xLOGIC’s VIGIL Client - Users Guide Page 21
Doc# 12031914
Sequence Tab
The Sequence tab configures the camera display sequences for the analog output monitors. Only analog video
feeds can be added to a sequence. This is due to hardware limitations on the capture cards.
Monitor Number Select the analog output monitor number for the sequence.
Auto Start
Sequence
When enabled, the sequence for the selected analog output monitor is started automatically when
VIGIL Server starts.
Add Add a new camera to the sequence with a specified dwell time.
Edit Modify the dwell time of the selected camera.
Delete Remove the selected camera from the sequence.
Up / Down Moves the selected camera up/down in the sequence.
Auto Logon
When this is checked, a message prompts for a username and password. The username and password entered
will be used to log into VIGIL Server automatically when the program is launched.
Data Drive Settings
The Data Drive Settings area displays the data drive information of the DVR.
The path of the drive and the
available/total space of the drive are displayed.
The status of the data drive is indicated by its icon:
Configured drive
Currently recording on this drive
Drive warning
Drive error, contact your system administrator.
