PICTURE SCREEN ADJUSTMENT (COMPUTER MODE)
This projector can adjust the image size and pan the image with PICTURE SCREEN ADJUSTMENT.
1. Press MENU BUTTON and MAIN MENU DISPLAY dialog box will appear.
2. Press POINT LEFT/RIGHT BUTTON (s) to select SCREEN and press SELECT BUTTON. Another dialog box
SCREEN ADJUST DISPLAY will appear.
3. Press POINT DOWN BUTTON and a red arrow will appear.
4. To adjust the image size or pan the image, move the arrow to Digital zoom by pressing POINT UP/DOWN
BUTTON(s) and then press SELECT BUTTON. MAIN MENU DISPLAY and SCREEN ADJUST DISPLAY will
disappear and the message "QuiT is displayed to indicate Digital Zoom mode.
5. To expand the image size, press SELECT BUTTON. The image is magnified by degrees (Expand function).
6. To compress the image size, press RIGHT CLICK BUTTON. The size of image is reduced by degrees
(Compress function).
7. To pan the image, press POINT UPTTOWN/LEFT/RIGHT (JOYSTICK) BUTTON(s). The image move to the
direction indicated (panning function).
8. To cancel Digital Zoom mode, press other buttons (except NO SHOW button).
9. To turn the image size to true size (1024 x 768 in XGA or SXGA. 800 x 600 in SVGA and 640 x 480 in VGA),
move the arrow to True by pressing POINT UP/DOWN BUTTON(s) and then press SELECT BUTTON. The
image size is turned to the true size.
■i.,. ■ VGA 1
SCREEN ADJUST I
DISPLAY
This projector cannot display in the resolution more than 1280 x 1024. If your computer’s screen resolution is
higher than 1280 x 1024, reset the resolution to the lower before connecting the projector.
The image data of VGA (640 x 480), SVGA (800 x 600) or SXGA (1280 x 1024) is modified to fit the screen
size in the initial mode.
The maximum size in expand mode is 4 times as large as the screen size (1024 x 768).
The minimum size in compress mode is the screen size (1024 x 768) in XGA or SXGA mode. 800 x 600 in
SVGA mode or 640 x 480 in VGA mode.
Panning function can work only when the image is expanded.
■43 ■
