CONNECTING THE PROJECTOR
• Your projector is equipped with various audioArideo inputs and outputs including Computer HDB15-pin (VGA) term^H
-lonitor HDBI 5-pin (VGA) terminals and S-VHS video . IP
CONNECTING THE COMPUTER
CONNECTING TO THE COMPUTER INPUT HDB15-PIN (VGA) TERMINALS (1 and 2 Ì
Personal computers can be connected to the HDB15-pin (VGA) terminai on the projector,
• Connect the computer to these terminais using the VGA cable and VGA/MAC adapter (provided).
WARNING: For projectors, the VGA cable provided is designed to reduce RFI (Radio Frequency Interference
emissions. For reguSatory compliance reasons, this cable must be used and must not be replaced by an
other cable.
CONNECTING TO THE MONITOR OUTPUT HDB15-P1N (VGA) TERMINAL
This terminal contains the information that is viewed on the screen.
An extemaimonitor can be connected to the HDB15-pin (VGA) terminal on the projector.
• Connect the monitor to this termina! using a monitor cable (not provided).
HD815-PIN
TERMINAL
Pin No./Signal Pin No./Signal
1 Red input 9 Non Connect
5'4 3-2 ^
0 0 0 - 0 0
2 Green input 1Q Ground (Vert, syns
3 Blue input 11 Sense 0
10 9-8 7 6."_7
0 - 0-0 0 o 7
4 Sense 2 12 Sense 1
I o’o b o*.b' 7.
5 Ground (Horiz. sync.) 13 Horiz. sync.
VJ5'1-413t2i1 yt 6 Ground (Red) 14 Vert. sync.
7 Ground (Green)
8- Ground (Blue) 15 Reserved
CONNECTING TO THE COMPUTER AUDIO INPUT JACKS (1 and 2)
• Connect audio outputs from your computer to these jacks using the audio cable (not provided).
CONNECTING TO THE MULTI-POLE 12-PiN (CONTROL PORT) CONNECTORS (1 and 2 )
• If you wish to control the computer with projector’s remote control unit, you must connect control port (PS/2, Serial c
ADB port) on your computer to projector’s control port with cable, (three type of cables provided)
CONTROL PORT
.1
2-
6
8
10
11
d2
PS/2=
,i=*ort
CLK
DATA
GND
Serial
Poii
TxD
RxD
READY
GND
ADBirj:
iPo'rt
ADB
GND
CONTROL PORT CABLE
REMOVAL HINT
Disconnect control port cable
with foilowing steps.
1. Hold the portion (A) of the
connector with one hand,
2. Pull the portion (B) arrow
direction and remove
connector.
iXL
~B.
A
NOTE: The RxD port (5 pin on the' Serial Port) is provided on control port 2 connector only. If you control the proje^
by computer, you must connect control port 2 connector.
