CONNECTING THE VIDEO E0ÜÍPMÉNT
CONNECTING TO THE AV INPUT 1 JACKS
'onnect to the video and audio outputs of a VCR, video disc player, video camera, satellite TV tuner or other AV
quipment.
• Connect audio/video outputs from external sources to these input jacks using the audio/video cable.
• If the audio signal from the AV equipment is stereo, be sure to connect the right and left channels to the respective right
and left audio input jacks.
• If the external audio signal is monaural, connect it to the left jack.
S-VHS FORMAT VCR CONNECTION
The AV 1 input includes an extra video input jack marked S-ViDEO to allow connection to an S-VHS format VCR that has
separate Y/C video signals. The S-VIDEO jack has priority over the VIDEO jack.
CONNECTING TO THE AV INPUT 2 JACKS
Connect to the video and audio outputs of a VCR, video disc player, video camera, satellite TV tuner or other AV
equipment,
• Connect audio.Video outputs from external sources to these input jacks using the audio/video cable.
• If the audio signal from the AV equipment is stereo, be sure to connect the right and left channels to the respective right
and left audio input jacks.
• If the external audio signal is monaural, connect it to the left jack.
h
15 •
