PROXIMA®
Desktop
QUICK
REFERENI
GUIQE
2300
The Proxima® Desktop Projector*'’^^ and Remote Control:
1
)
2
)
3)
4)
5}
6
)
7)
8
)
Control Panel
Mirror Assembly
Cover Assembly
Top Air Intake Filter
Recessed Carrying Handle
Front Air Intake Filters
Cyclops Lens
Projection Lens Assembly
and Focus Ring
9) Remote Control
10) Connector Panel
11) Lamp Selector
12) Lamp Chamber Latch
13) Power Cord Receptacle
14) Power Switch
15) Circuit Breaker Reset Button
