Chapter g
Detailed Setup
Keystoning
The normal projected Image will have a rectangular shape.
Keystoning is when the projected image becomes trapezoidal.
800
600
400
200
0
_ ||H
h
P
APR I MAY I JUN
j
JUL |
IMormat Image
Keystoned Image
FigeMre 1S
Normal ve. keystoned imsges
Keystoning occurs when the front of the Desktop Projector is not
perpendicular to the projection screen (the vertical plane) or when
it’s not placed parallel to the floor {the horizontal plane).
Keystoning also occurs when the Desktop Projector is tilted
sidewaj's.
Dser’s Guide • 2-10
