Model 527
PARTS LIST FOR MODEL 527 LAWN TRACTOR
.<0.
PART
NO.
CODE DESCRIPTION
REF.
NO.
PART
NO.
CODE DESCRIPTION
1 710-0198 Hex Sems Bolt 5/16-18 x 51 738-0140 Shid. Bolt .437" Dia. x .18"
.75" Lg.* 52 12484 Idler Brkt. Ass’y.
2 732-0541 Seat Spring 54 HH-12-03293 Casting—Carrier
3 726-0151 Fastener (Self Ret. V a Turn) 55 738-0129 1 ShId. Bolt .498" Dia. x 2.0"
4 12471A 638 Rear Frame Cover 56 HH-15-03149 Pad—Friction
5 12450A 638 Rear Frame 57 734-0715 Rear Wheel Ass’y.—Comp.
6 726-0121 Push Cap .25" Dia.—Black 14.5 X 4.5
7 712-0267 Hex Nut 5/16-18 Thd.* 734-0714 Tire Only 14.5 x 4.5
8 736-0119 L-Wash. 5/16" I.D.* 58 734-0517 Rear Wheel Rim Only
9 720-0165 Ball Knob 59 736-0242 Bell-Wash. .345 I.D. x .88
10 11545 Shift Lever—Transmission 60 710-0627 Hex Cent. Lock Scr. 5/16-24
11 713-0189 #420 Chain Vz" Pitch x 77
X .75" Lg. H.T.
Links 61 717-0319 Differential Ass’y. Comp.
12 712-0154 #420 Master Link 62 HH-15-02124 Pad—Fricion
13 710-0513 Hex Bolt 1/4-28 X .62" Lg. 63 HH-03-03303 Disc—Back-Up
(Lock) 64 12853 Seat Support Ass’y.
14 736-0270 Bell-Wash. .25" I.D. X .88 65 12508 Rear Axle Plate
O.D. X .062" 66 741-0199 Flange Brg. w/Flats .753" I.D.
15 712-0158 Hex Cent. L-Nut 5/16-18 67 710-0322 Hex Sems Bolt 5/16-18 x 1.0"
Thd. Lg.*
16 736-0159 FI-Wash. .344" I.D. x .88" O.D. 68 736-0134 FI-Wash. .812" I.D. x 1.38"
17 735-0126 Rubber Wash. .33" I.D. x .87" O.D. X .10"
18 11548 Shift Lever Brkt. Ass’y. 69 12482 Disc Brake Brkt. Ass’y.
19 717-0234 Hardened Wash. 1.0" O.D. 70 — Transmission (Five Speed)
(Special) 71 HH-12-03292 Casting—Cam
712-0798 Hex Nut 3/8-16 Thd.* 72 HH-05-03034 Push Pin
736-0171 L-Wash. 7/16" I.D. 73 761-0130 Disc Brake Ass’y.—Comp.
12 747-0155 Brake Rod 74 710-0437 Chain Adj. Link 5/16-18 x
23 732-0233 Extension Spring 4.38" Lg.
25 16023 Clutch Lockout Ass’y. 75 12460 Rear Axle Brkt.—R.H.
26 714-0507 Cotter Pin 3/32" Dia. x .75"* 76 732-0245 Brake Spring
27 12379 Clutch Pedal Pad 77 HH-18-03493 Cam Lever
28 710-0118 Hex Bolt 5/16-18 X .75" Lg.* 78 12459 Rear Axle Brkt.—L.H.
29 12539 Clutch Pedal & Brkt. Ass’y. 79 732-0157 Brake Return Spring
30 12486 Brake Lever Ass’y. 80 10360 Plate Ass’y. Axle Bolt
31 710-0378 Hex Bolt 5/16-18 X 2.5" Lg. 81 HH-03-03032 Washer
32 747-0156 Clutch Rod 82 710-0425 Truss Hd. Mach. Scr. #10-24
33 710-0316 Hex Bolt 3/8-16 X 3.5" Lg.
X .62" Lg.
34 710-0211 Hex Sems Bolt V4-20 x .75"* 83 12537 Baffle Plate
35 12488 Engine Belt Guard Ass’y. 84 736-0147 Ext. L-Wash.
36 12534 Pedal “U” Brkt.—R.H. 85 712-0121 Hex Nut 10-24 Thd.*
37 715-0114 Spring Pin Spiral .25" Dia. x 86 712-0429 Hex Ins. L-Nut 5/16-18 Thd.
1.5" Lg. 87 736-0329 L-Wash.
1
/
4
" I.D.*
38 761-0133 Bushing 88 712-0287 Hex Nut
1
/
4-20
Thd.*
39 12543 Brake Pedal Shaft Ass’y. 89 738-0143 Shid Bolt .498" Dia. x .33"
40 12378 Brake Pedal Pad 90 712-0134 Hex Top L-Nut
41 756-0436 Two-Step Engine Pulley 91 HH-06-03031 Spring
42 712-0116 Hex Ins. L-Nut 3/8-24 Thd. 92 12541 Chute Pivot Brkt.
43 756-0217 Fl-ldler w/Flanges 2.75" Dia. 93 714-0114 Sq.-Key
1/4 X 2.0" Lg.
44 712-0922 Hex Jam Nut V
2-20
Thd.* 94 12544A 637 Grass Catcher Adapter
45 736-0921 L-Wash.
1
/
2
" I.D. 95 710-0289 Hex Bolt
1
/
4-20 X .50" Lg.*
46 754-0198 “V”-Belt (Drive) 96 725-0577 Safety Switch
47 756-0174 Transmission Split Pulley 98 736-0105 Belleville Washer
.50" I.D. 99 710-0227 Hex Wash. Hd. Scr. #8 x .50"
714-0129 #4 Hi-Pro Key 3/32 X 5/8" Dia. 100 726-0222 Insulator Nut Plate
’9 710-0757 Hex Bolt 7/16-20 x 1.5" Lg. 101 725-0759 Spring Switch
^0 756-0116 “V”-ldler 102 15734 Rear Chute Baffle (Optional)
27
