Model 527
PARTS LIST FOR MODEL 527 LAWN TRACTOR
e.
,*o.
PART
NO.
CODE DESCRIPTION
REF.
NO.
PART
NO.
CODE DESCRIPTION
1 720-0165 Ball Knob 51 712-0123 Hex Nut 5/16-24 Thd.*
2 710-0286 Truss Mach. Scr. 1/4-20 x 52 738-0292 Blade Spindle
.50" Lg.* 53 12532 Deck Bracket (Chute)
3 712-0287 Hex Nut 1/4-20 Thd.* 54 738-0183 Shid. Scr. .5" Dia. x .17" Lg.
4 725-0465A N Safety Switch (Blade Clutch) 55 736-0140 FI-Wash. .385" I.D. X .88" O.D.
5 710-0282 Weld Pin .25" Dia. x .62" Lg. 56 712-0375 Hex Cent. L-Nut 3/8-16 Thd.
6 726-0106 Push Cap .25" Dia. 57 12464 637 Chute Ass’y-
7 761-0145 Clevis 58 712-0429 Hex Ins. L-Nut 5/16-18 Thd.
8 712-0256 Hex Jam Nut 5/16-24 Thd.* 59 736-0242 Bell-Wsh. .345" I.D. x .88"
9 736-0119 L-Wash. 5/16" I.D. 60 12541 Chute Pivot Brkt.
10 736-0219 Bell-Wash. .40" I.D. x 1.11" 61 738-0140 ShId. Bolt .437 I.D. x .18" Lg.
11 710-0502 Hex Wash. Hd. Self-Tap 62 750-0258 Spacer .315" I.D. x .75" O.D. x
Scr. 3/8-16 X 1.25" Lg. .37 Lg.
12 714-0101 Internal Cot-Pin Vi" Dia. 63 736-0231 FI-Wash. .344" I.D. X 1.12"
13 710-0106 Hex Bolt 1/4-20 X 1.25" Lg.* O.D. X .12
14 12476A N Deck Clutch Control Brkt. 64 710-0376 Hex Bolt 5/16-18 X 1.0" Lg.
15 736-0173 FI-Wash. .28" I.D. x .75" O.D. 65 732-0308 Extension Spring
X .063 66 12469A N Deck Idler Brkt. Ass’y.
16 747-0157 Blade Clutch Lever 67 756-0116 V-ldler Pulley
17 735-0165 Rubber Washer 68 736-0116 FI-Wash. .63" I.D. X .93" O.D.
18 712-0107 Hex Cent. L-Nut V4-20 Thd. X .06"
19 712-0261 Hex Nut 5/8-11 Thd.* 69 12472 Lift Handle Shaft Ass’y.
20 736-0158 L-Wash. 5/8" I.D.* 71 12477 Rubber Wash.
21 756-0143 Deck Pulley 72 749-0174 Lift Handle
22 754-0195A N “V”-Belt 73 12479 Lift Handle Stop
748-0168 Spacer 74 11249 Height Adj. Knob
710-0322 Hex Sems Bolt 5/16-18 x 1.0" 75 1247 Lift Arm Shaft Ass’y.
Lg.* 76 10317 Deck Link
25 08253B Bearing Housing 77 12502 Lift Pivot Brkt. Ass’y.
26 741-0919 Ball Brg. .787" I.D. x 1.85" O.D. 80 12853 Seat Support Ass’y.
27 12453 Deck Belt Guard Plate 81 720-0157 Grip
28 710-0211 Hex Sems Bolt 1/4-20 x .75"* 82 710-0597 Hex Sems Bolt V4-20 x 1.0" Lg.*
29 711-0332 Lift Brkt. Pin Special 83 12495 Connecting Link
30 732-0180 Extension Spring .88" O.D. x 4" 84 710-0627 Hex Wash. Hd. Self-Tap Scr.
Lg. 5/16-24 X .75" Lg.
31 736-0329 L-Wash. 1/4" I.D.* 85 10426 Belt Keeper Ass’y.
33 12509 Cabie Bracket 86 15296 Open Bearing Hsg.
34 746-0253 Clutch Control Cable 26.88" Lg. 87 714-0507 Cotter Pin 3/32" Dia. x .75"
35 714-0365 #6 Hi-Pro Key 5/32 x 5/8" Dia. 88 748-0176 Flange Brg. .62" I.D. x .87"
36 712-0267 Hex Nut 5/16-18 Thd.* O.D. X .63" Lg.
38 12531 Deck Bracket 89 712-0116 Hex Ins. L-Nut 3/8-24 Thd.
39 710-0451 Carriage Bolt 5/16-18 x .75"* 90 736-0160 FI-Wash. .53" I.D. x .94" O.D.
40 14248 637 26" Deck Ass’y. Comp. X .050"
41 750-0142 Spacer .836" I.D. x 1.01" O.D. 91 735-0185 Rubber Wash. .531" I.D. x 1.0"
X .32" Lg. O.D. X .120"
42 714-0388 #61 Hi-Pro Key 3/16 X 5/8" Dia. 92 736-0192 FI-Wash. .531" I.D. x .93"
43 736-0119 L-Wash. 5/16" I.D.* O.D. X .090"
44 712-0267 Hex Nut 5/16-18 Thd.* 93 12852 Chute Baffle
45 742-0255A 26" Blade 94 710-0167 Carriage Bolt V4-20 x .50" *
46 736-0217 L-Wash. 3/8" I.D. H.D. 95 711-0310 Clevis Pin .50"
47 710-0151 Hex Bolt 3/8-24 X 2.0" Lg. H.T. 96 710-0413 Self-Tap Scr. 3/16-16 x 1.0"
48 710-0624 Hex Bolt 5/16-24 x 1.5" Lg. 97 731-0339 Shrink Tube
H.T.—Special 98 13703 Bearing Shield
49 748-0189 Blade Adapter 99 12626A Spacer
25
