Model 527
PARTS LIST FOR MODEL 527 LAWN TRACTOR
F.
.40.
PART
NO.
CODE DESCRIPTION
REF.
NO.
PART
NO.
CODE DESCRIPTION
1 731-0220 Steering Wheel Cap 42 13274 638 Pivot Bar Ass’y.
2 712-0158 Hex Cent. L-Nut 5/16-18 Thd. 43 714-0474 Cotter Pin 1/8" Dia. x .75" Lg.*
3 736-0242 Bell-Wash. .345 I.D. x .88 O.D. 44
* ★
Front Wheel Ass’y.—
4 731-0219 Steering Wheel (See Chart Below)
5 741-0225 Hex Flange Bushing .63" I.D. 45 741-0487 Flange Bearing
6 723-0333 Fuel Gauge—Cap 46 12491A 638 Front Axle Ass’y.—L.H.
7 16548 Dash Panel Ass’y- w/Lights 47 711-0198 Pivot Bushing
8 735-0179 Rubber Grommet (Fuel 48 712-0711 Hex Jam Nut 3/8-24 Thd.*
Tank Neck) 49 747-0144 Tie Rod
9 710-0211 Hex Sems Scr. Vi-20 x .75" Lg.* 50 712-0116 Hex Ins. L-Nut 3/8-24 Thd.
10 751-0172 Fuel Tank 51 710-0289 Hex Bolt 1/4-29 X .5" Lg.*
11 726-0209 Cable Tie (Fuei Tank) 52 723-0156 Ball Joint Ass’y.
12 722-0153 Engine Mounting Grommet 53 712-0711 Hex Jam Nut 3/8-24 Thd.*
13 736-0400 FI-Wash. .218" I.D. x .62" 54 747-0158 Drag Link
14 710-0899A N Hex Sems Scr. 55 714-0470 Cotter Pin 1/8" Dia. x 1.25" Lg.*
#10-32 X .62" Lg. 56 736-0156 FI-Wash. .63" I.D. X 1.12"
15 750-0539 Spacer O.D. X .10"
16 710-0654A N Hex Wash. Hd. Self-Tap 57 12492A 638 Front Axle Ass’y.—R.H.
Scr. 3/8-16 x 1.0" Lg. 59 710-0198 Hex Sems Scr. 5/16-18 x
17
—
Engine .75" Lg.*
18 712-0123 Hex Nut 5/16-24 Thd.* 60 741-0199 Flange Brg. w/Flats
19 736-0119 L-Wash. 5/16" I.D.* 61 12600 638 Front Frame Ass’y.
20 736-0231 FI-Wash. .34" I.D. x 1.12" 62 723-0306 Foot Pad—R.H.
O.D. x .125 63 12450 638 Rear Frame
21 712-0267 Hex Nut 5/16-18 Thd.* 64 736-0264 FI-Wash. 5/16" I.D.
736-0119 L-Wash. 5/16" I.D.* 65 748-0236 Side Gear
^3 12467 638 Front Pivot Bracket 66 12851 Steering Gear Support Ass’y.
.4 736-0158 L-Wash. 5/8" I.D.* 67 731-0484A N Hub Cap
25 712-0923 Hex Cent. L-Nut 5/8-18 Thd. 68 741-0226 Hex Flange Bushing .50" I.D.
26 710-0158 Hex Bolt 5/16-24 X 1.25 H.T. 69 748-0237 Pinion Gear
27 16040 Engine Base Plate 70 738-0325 Steering Shaft
29 736-0329 L-Wash. 1/4" Scr.* 72 736-0222 Ext. L-Wash. 1/4" I.D.*
30 712-0287 Hex Nut 1/4-20 Thd.* 75 725-0771 Solenoid
31 712-0267 Hex Nut 5/16-18 Thd.* 76 710-0670 Hex Bolt Nylon 3/8-16 x 1.25"
32 736-0119 L-Wash. 5/16" I.D.*
Lg-
33 736-0134 FI-Wash. .812" I.D. x 1.38" 77 712-0375 Hex Cent. L-Nut 3/8-16 Thd.
O.D. X .100 79 712-0287 Hex Nut 1/4-20 Thd.*
34 723-0307 Foot Pad—L.H. 80 712-0237 Hex Cent. L-Nut 5/16-24 Thd.
35 741-0199 Flange Brg. w/Flats 81 710-0180 Hex Bolt 3/8-24 x .75" Lg.*
36 714-0507 Cotter Pin 3/32" Dia. x .75"* 82 736-0105 Bell-Wash.
37 12815 Steering Arm Ass’y. 85 726-0205 Hose Clamps (2 Required)
38 710-0622 Hex Bolt 5/8-18 x 1.62" Lg. 86 751-0535 Fuei Line 15" Lg.
39 710-0198 Hex Sems Bolt 5/16-18 x .75" 87 16778 Throttle Limiter
Lg.* 88 751-0423 Muffler
40 726-0159B N Push Nut 721-0208 Exhaust Gasket
41 741-0225 Hex Flange Bushing .62" I.D. 751-0424
‘Front Wheel Available
Front Wheel Pneumatic
Assembly Comp.
Tire Only
Rim Only
Grease Fitting
734-1454
734-1382
734-1455
737-0146
CODE: N notates a new part (not previously existing). A three digit
number is the color code. Specify color code as shown if color
or finish is important when ordering parts [i.e., 638 for Red Finish],
Color Codes
*For faster service obtain standard nuts, bolts and washers locally.
If these items cannot be obtained locally, order by part number and
size as shown on parts list.
456—Radiant Tangerine 629—Silver Flake
460—Green Flake 630—Metallic Blue
483—Charcoal Gray 637—Black
498—Yellow 638—Red
499—Beige 640—Green
621—Brilliant Fire Mist 646—CM Blue
