PARTS LIST FOR MODEL 527 LAWN TRACTOR
TEF.
NO.
PART
NO.
CODE
DESCRIPTION
REF.
NO.
PART
NO.
CODE
DESCRIPTION
1
12903
Screen—Grille
32 710-0134
Carriage Bolt V4-20 x .62"*
2
12901
638
Grille Ass’y.
33 12712
638
Fender Ass’y. R.H.
3
725-0417
Headlight
34 710-0258
Hex Bolt
1
/
4-20
X
.62" Lg.*
4
10795
Headlight Retainer
35 723-0296
Hood Lock Ass’y.
5 712-0121
Hex Nut #10-24 Thd.
37 736-0147
Wash. #10 I.D.
6
736-0722
L-Wash. #10 I.D.
38 710-0425
Truss Hd. Mach. Scr. #10-24 x
10 831-0823A
Throttle Control Box Ass’y-
.62" Lg.*
11
746-0500
Throttle Control Wire
39 712-0206
Hex Nut
1
/
2-13
Thd.*
13
12451
638
Hood—Front
40 736-0921
L-Wash.
1
/
2
" I.D.*
14
710-0286
Truss Hd. Mach. Scr. Vi-20 x
41 725-1341B
Ignition Key
.50" Lg.*
42 725-0267
Ignition Switch
17
712-0287
Hex Nut V4-20 Thd.*
43 757-0285
Seat Ass’y.
18
736-0329
L-Wash.
1
/
4
" I.D. *
46 726-0156
Speed Nut 10-24
20
710-0253
Hex Bolt 3/8-16
X
1" Lg.*
47 725-0459
Circuit Breaker
)21
710-0211
Hex Sems Bolt V4-20 x .75"
49 711-0222
Hold-Down Rod
“>
712-0375
Hex Cent. L-Nut 3/8-16 Thd.
51 712-0113
Wing Nut
1
/
4-20
Thd.
736-0140
FI-Wash. .385" I.D. x .62" O.D.
52 731-0708
Battery Cover
24
736-0105
Bell-Wash. .4" I.D. x .88"
55 725-0514A
12V Battery
27
12715
638
Fender Ass’y. L.H.
— 746-0616A
Choke Control (Not Shown)
