Sears 917.25591 - Manual (Page 37)

тшш%ш
PARIS
MOWER
GT 18 TWIN GARDEN TRACTOR-MODEL NUMBER 917.255910
KEY
РДД-,-
DESCRIPTION KEY DESCRIPTION
NO. NO. NO. NO.
1 106579X Housing, Mower 35 73680600 Nut, Crown lock 3/8 !• 16
2 106022X Cover • Drive, Deck 36 105453X Bar, Ga, Wheel
3 17490508 Screw* Hex Washer Thd, Roll 5/16 - 37 5585J Pin, Clevis
18 X 1/2 38 4939M Retainer, Spring
4 7631J Runner, L.H. 39 4898H Bolt, Shoulder
5 72110505 Bolt, Carr. 5/16- 18 X 5/8 40 105455X Wheel, Gauge
6 STD55!13t *W3sher»Lock, 5/16 41 105433X Brkt., Suspension
7 STO541031 * Nut-Hex 5/16-18 42 105430X Spacer
8 84 W Runner, R.H. 43 10Б434Х Brace, Suspension
9 72140506 Bolt, Carr, 5/16 - 18 x 3/4 44 105436X Parallel Link
10 168SH Nut, Lock 5/16 - 18 45 10544IX Brkt, Suspension
If STD551031 *Washer 11/32 x 11/16 x 16 Oa. 46 78850 Decal - Warning
12 105194X Mandrel - Secondary A-7 9135R Retainer - Spring
13 106038X Mandrel - Primary 48 10638IX V-Belt
14 17490612 Screw ' Hex Washer Thd. Roll 3/8 - 49 STD541050 *Nut, 1/2- 13
16x3/4 50 74760622 Bolt, Hex 3/8 - 16 X 1.3/8
15tHb,i^.iJ06B36X Blade - v-in..s JtsotqsiA SI 105435X Pin, Release
16 STD6237I5 *Bolt - Hex, 3/8 - 24 X 1 - 1/2 Gr. 5 52 3720R Spring
17 STD551137 *Washer-Lock, 3/8 53 12000039 Ring, Klip
18 19132012 Washer 13/32 x 1 - 1/4 x 12 Ga. 54 19171612 Washer 17/32 x 1 x l2Ga.
19 674A213 Arm Assembly, Idler 55 105440X Pin, Clevis
20 7834J Liner, Bearing 56 105456X Brkt, Outer, R.H.
21 7835J Bearing 57 10Б460Х Brkt., Inner, R.H.
22 72110522 Bolt, Carriage 5/16 - !8 x 2 - 3/4 58 10546IX Brkt., Inner, L.H.
23 19111610 Washer 11/32 X 1 x lOGa. 59 1054Б7Х Brkt., Outer, L.H.
24 102403X Pulley, Idler 60 73680500 Locknut 5/16-18
25 STD523715 *Bolt- Hex3/8- 16x 1 - 1/2 62 19111016 Washer 11/32 x 5/8 x 16 Ga.
26 STD541037 *Nut- Hex 3/8- 16 63 1058Э5Х Shield, Deflector
27 104361X Spring 64 10655IX Spring, Deflector
28 STD523112 *8olt - Hex 5/16-18x1-1/4 Gr. 5 65 1058Э6Х Bracket, Deflector
29 19111216 Washer 11/32 x 3/4 x 16 Ga. 66 106520X Rod, Hinge
30 8438J Spacer 68 5846R Push Nut
31 106224X Decat * V-Be!t, Dr„ Schematic, Mower 69 3713J Instruction » Caution Decal
32 105448X Bracket, Ga. Wheel, R,H. 70- ss S&S^5224J Decal - Safety Standard
33 105449X Bracket, Ga. Wheel, L.H, 71 i 73680800 Nut-Hex 1/2- 13
34 STD533707 *Bolt, Carriage 3/8 - 16 x 3/4 72 PV41 .#06674Х Plate- Spacer, Mandrel ;
^STANDARD HARDWARE-PURCHASE LOCALLY
34
Я
f
35
Б0 14
ho ® 35
6
©7
«37'
