Table IB — Physical Data 50 Hz
English
09DK 054 064 074 084 094
NOMINAL TONS 50 60 70 80 90
OPERATING WEIGHT-lb
Cu-AI* 1695 1845 2200 2421 2850
Cu-Cut 1983 2278 2617 3099 3560
SHIPPING WEIGHT-lb"
Cu-AI* 2010 2136 2521 2725 4415
Cu-Cut 2298 2569 2938 3403 5150
REFRIGERANTS R-134A, R-22, R-12, R-500, R-502
NOMINAL HEAT REJECTION
(TONS)tt
65 8 78.6 95.4 103 5 116.3
CONDENSER FANS
No. of Blades 6 6 6 6 6
No. of Fans 4 4 6 6 6
Fan Diameter-in. 30 30 30 30 30
Airfiow-cfm 35,000 35,000 52,000 51,000 57,000
Fan Speed-rpm 950 950 950 950 950
Fan Motor-hp 1 1 1 1 1
CONDENSER COILS 4
Quantity 4 4 4 4 4
Fins/in. 17 17 17 17 17
No. of Rows 2 3 2 3 3
Totai Face Area (sq ft) 80.5 80.5 1167 116.7 128.3
TD — Temperature Difference = Saturated Condensing Temperature - Entering-Air Temperature
'Copper tubes and aluminum fins.
tCopper tubes and copper fins
"Packaging option includes skid and coil protection.
ttNominal heat rejection based on refrigerant R-22, 15° F subcooling, and a 30° F temperature difference (TD)
SI
09DK 054 064 074 084 094
NOMINAL kW 176 211 246 281 316
OPERATING WEIGHT-kg
Cu-AI* 769 837 998 1098 1293
Cu-Cut 900 1033 1187 1406 1615
SHIPPING WEIGHT-kg**
Cu-AI* 912 969 1144 1236 2003
Cu-Cut 1042 1165 1333 1544 2336
REFRIGERANTS R-134A, R-22, R-12, R-500 R-502
NOMINAL HEAT REJECTION
(kW)tt
231 276 335 364 409
CONDENSER FANS
No. Of Blades 6 6 6 6 6
No. of Fans 4 4 6 6 6
Fan Diameter-mm 762 762 762 762 762
Airflow-L/s 16 520 16 520 24 540 24 070 26 900
Fan Speed-r/s 15.8 158 15.8 158 15.8
Fan Motor-kW 0.746 0.746 0.746 0.746 0.746
CONDENSER COILS
Quantity 4 4 4 4 4
Fins/m 669 669 669 669 669
No. of Rows 2 3 2 3 3
Total Face Area (sq m) 7.5 7.5 10 84 10 84 11.92
TD — Temperature Difference = Saturated Condensing Temperature - Entering-Air Temperature
‘Copper tubes and aluminum fins.
tCopper tubes and copper fins.
"Packaging option includes skid and coil protection.
ttNominal heat rejection based on refrigerant R-22, 8.3° C subcooling, and a 16.7° C temperature difference (TD).
