LEFTSIDE COILS RIGHT SIDE COILS
054,064
PERCENT CAPACITY
SPLIT
LINE TYPE
COIL CONNECTION
NUMBER
COIL CONNECTION
in.-ODM*
TUBING CONNECTION
in. ODMf
Hot Gas 1,3,5,7 1 1/8 1 5/8
Liquid 2,4,6,8 7/8 1 1/8
Hot Gas 1,3/5,7 1 1/8 1 3/8 1 3/8
Liquid 2,4/6,8 7/8 7/8 7/8
Hot Gas 1,3,5/7 1 1/8 1 3/8 1 1/8
Liquid 2,4,6/8 7/8 7/8 7/8
Hot Gas 1/7/3,5 1 1/8 (3) 1/8
Liquid 2/8/4,6 7/8 (3) 7/8
34/34/16/16
Hot Gas
Liquid
1/7/3/5
2/8/4/6 1 1/8
7/8
•Connection sizes reflect size of each coll header nozzle
tA tubing package is factory supplied to facilitate field piping installation for the 100, 50/50 and 66/34% capacity split applications See Fig 5
074
PERCENT CAPACITY
SPLIT
LINE TYPE
COIL CONNECTION
NUMBER
COIL CONNECTION
in.-ODM*
TUBING CONNECTION
in.-ODMt
Hot Gas 1,3,5,7 1 3/8 2 1/8
Liquid 2,4,6,8 7/8 1 1/8
Hot Gas 1,3/5,7 1 3/8 1 5/8 1 5/8
Liquid 2,4/6,8 7/8 7/8 7/8
Hot Gas 1,3,5/7 1 3/8 1 5/8 1 3/8
Liquid 2,4,6/8 7/8 7/8 7/8
Hot Gas 1/7/3,5 1 3/8 (3) 1 3/8
Liquid 2/8/4,6 7/8 (3) 7/8
32/32/18/18
Hot Gas
Liquid
1/7/3/5
2/8/4/6 1 3/8
7/8
•Connection sizes reflect size of each coil header nozzle
tA tubing package is factory supplied to facilitate field piping installation for the 100, 50/50 and 68/32% capacity split applications. See Fig 6.
084
PERCENT CAPACITY
SPLIT
LINE TYPE
COIL CONNECTION
NUMBER
COIL CONNECTION
in.-ODM*
TUBING CONNECTION
In.-ODMt
Hot Gas 1,3,5,7 1 3/8 2 1/8
Liquid 2,4,6,8 7/8 1 1/8
50/50
Hot Gas 1,3/5,7 1 3/8 1 5/8 1 5/8
Liquid 2,4/6,8 7/8 7/8 7/8
Hot Gas 1,3,5/7 1 3/8 1 5/8 1 3/8
Liquid 2,4,6/8 7/8 1 1/8 7/8
Hot Gas 1/7/3,5 1 3/8 (3) 1 3/8
Liquid 2/8/4,6 7/8 (3) 7/8
33/33/17/17
Hot Gas
Liquid
1/7/3/5
2/8/4/6 1 3/8
7/8 #
•Connection sizes reflect size of each coil header nozzle
fA tubing package is factory supplied to facilitate field piping installation for the 100, 50/50 and 67/33% capacity split applications See Fig 6
Fig. 10 — Coil Connection Data, 09DK054-084
