Table 4 — 09DK Electrical Data

NAMEPLATE

V-PH-HZ

SUPPLY VOLTAGE*

FAN MOTORS

09DK

Min

Max

MCA

MOCP

NO. FANS

Total Kw

(Fan no.)

FLA for ea. fan

054,064

-500

208/230-3-60

187

254

23.2

25

4

62

(1,2) 5.5 (3,4) 5 4

-600

460-3-60

414

508

11.7

15

4

62

(1,2) 2 8 (3,4) 2 7

-100

575-3-60

518

632

14.5

15

4

6.2

(1-4) 3.4

-200

380-3-60

342

418

16.6

20

4

6.2

(1-4) 3 9

-900

380/415-3-50

342

440

12.8

15

4

6.2

(1-4) 3.0

074,084,094

-500

208/230-3-60

187

254

34.0

35

6

9.3

(1,2) 5 5 (3-6) 5.4

-600

460-3-60

414

508

17.1

20

6

9.3

(1,2) 2.8 (3-6) 2 7

-100

575-3-60

518

632

21.3

25

6

9.3

(1-6)3 4

-200

380-3-60

342

418

24.4

25

6

93

(1-6)3 9

-900

380/415-3-50

342

440

18.8

20

6

93

(1-6) 3 0

Control Circuit Information

09DK

ALL

UNITS

CONTROL POWER

V-PH-HZ

SUPPLY

VOLTAGE*

OVERCURRENT

PROTECTION

AMPS

-500

115-1-60

103

127

10

-600

115-1-60

103

127

10

-100

115-1-60

103

127

10

-200

230-1-60

207

253

10

-900

230-1-50

207

253

10

LEGEND

FLA — Full Load Amps
MCA — Minimum Circuit Amps; Used for wire sizing

(Complies with NEC Section 430-24)

MOCP — Maximum Overcurrent Protection
NEC — National Electrical Code
'Units are suitable for use on electrical systems where voltage sup­
plied to the unit terminals is within listed minimum and maximum
limits.

NOTES:

1 Maximum allowable phase imbalance: Voltage ± 2%; Amps ± 10%.

2 Maximum incoming wire size for power circuit is 2/0 max.
3 Control Circuit: Uses no. 8 screws for wire connections at the ter­

minal block.

4 100 va is required for the 09DK054-094 control circuit

100%

Fig. 19 - 100% Coil Circuiting; 074 Units
