5. Multiply result of step 4 by the number of cu ft

shown for one revolution of test dial to obtain
cu ft of gas flow per hour.

6. Multiply result of step 5 by Btu heating value of

gas to obtain total measured input in Btuh. Com­
pare this value with heating input shown in

Table 4. Consult local gas supplier if the heating
value of gas is not known.

Example: Assume that the size of test dial is 1 cu ft,
one revolution takes 30 seconds and the heating

value of the gas is 1050 Btu perçu ft, then proceed as
follows:

a. 30 seconds to complete one revolution.
b. 30 divided into 3600 equals 120.
c.

120 times one equals 120cuft of gas flow per

hour.

d. 120 times 1050 equals 126,000 Btuh input.

If the desired gas input is 125,000 Btuh, only a

minor change in the manifold pressure is required.

Observe manifold pressure and proceed as follows

to adjust gas input:

1. Remove vented seal cap over REG ADJ screw

on gas valve.

2. Turn regulator adjustment screw clockwise to

increase gas input, or turn regulator adjustment
screw counterclockwise to decrease input. Mani­

fold pressure must be between 3.2 and 3.8 in. wg.
UNSAFE OPERATION OF THE UNIT MAY

RESULT

IF

MANIFOLD

PRESSURE

IS

OUTSIDE THIS RANGE.

3. Replace vented seal cap on gas valve.

4. Turn off gas supply to unit. Remove manometer

from pressure tap. Replace pipe plug on gas
valve. Turn on gas to unit. Check for leaks.

Measuring Manifold Pressure — LP (Propane) Gas
Units — The main burner orifices on a propane gas

unit are sized for the unit rated input when manifold
pressure is 10.5 in. wg.

Proceed as follows to adjust gas input on an LP

(propane) gas unit:

1. Turn off gas to unit.

2. Remove pipe plug on gas valve outlet identified

as PRESS. TAP, then connect manometer at this
point.

3. Turn on gas to unit.

4. Remove vented seal cap over REG ADJ screw on

gas valve.

5. Adjust regulator adjustment screw for a manifold

pressure reading of 10.5 in. wg. Turn adjusting
screw clockwise to increase manifold pressure, or
turn adjusting screw counterclockwise to de­
crease manifold pressure.

6. Turn off gas to unit. Remove manometer from

pressure tap. Replace pipe plug on gas valve, then
turn on gas to unit. Check for leaks.

ADJUSTING

BURNER

AIR

SHUTTERS

After burners have operated at full input for at least

10 minutes, adjust primary air to each burner to

ensure optimum heating performance. Make these
adjustments when unit is being installed and during
routine maintenance inspections at beginning of
each heating season.

Be sure each burner is clean and

free of deposits before adjusting primary air.

Primary air to each burner is regulated by burner

air shutter on each burner. See Fig. 9 for location
of burner air shutter. With all burners operating,
adjust primary air to each burner as follows:

1. Loosen locking screw that secures air shutter in

place on burner, then partially close air shutter
until a slight yellow tip appears on top of burner
flames.

2. Open air shutter

very slowly until yellow tip just

disappears, then secure air shutter in place with
locking screw.

3. Repeat steps 1 and 2 for each burner.

Table 4 — Rated Gas Inputs at Indicated Manifold Pressures

MODEL 48-

_ _ __

_

...

KL036.042

TtH042J

_

-

KL060

. |^H(536gF7CF ■

KH048BF/CF

KH060BE

KH devoir

NUMBER

OF

ORIFICES

3

4

5

5

..

g..

..

GAS SUPPLY

PRESSURE (in.wg)

Natural

Min

5 0

5.0

5 0

5 0

“B'O"

Max

T3”6~

13 6

Î3.B

13 6

13 6

T3 5“
13-F

LP (Propànêr

Max

T3“0 "

Min

11

0

11

0

Q-

11 0

11

0

11Ü

'ITU

13 0

13 0

13 0

130

1d.O
13 0'

MANIFOLD

PRESSURE

(in. wg)

Natural

3 5

3 5

3 5

3 5

..

gg...,

■ J5'^~

LP (Prop.)

10 5

10 5 ’

10 5

105

~ 10.5 ~

‘Based on altitudes from sea level up to 2000 feet above sea level

For altitudes above 2000 feet, reduce input rating 4% for each
1000 feet above sea level

NATURAL GAS

Heating

Orifice

P/N

LH32DB205

LH32DB205

LH32DB200'

LH32DB200

LH32DB207

tHOÎÜBZOO"

IH32DB2Ü7"

Input

(Btuh)*

40.000

60.000

■mooo"

100,000

125,000

T20dOCr

r50dO0

LP (Propane) GAS

Heating

Orifice

P/N

LH32DB201

LH32DB201

LH32DB201

LH32DB201

Input

(Btuh)*

40.000

60.000

‘Tó.odd

100,000

Not Available

IH32DB20T

120,000

Not Available

I 1
