6 | PIR Ready VT76x7 Series-Installation Guide
Network ready
 All Viconics VT76x7 series Terminal Equipment Controllers are designed for
stand-alone (Network Ready) operation.
 They can be fully integrated into your choice of automation systems using the
available communication adapter options.
 If required, stand-alone (Network Ready) Terminal Equipment Controllers can be
field retrofitted with the following communication adapters:
o VCM7607V5000B, Terminal Equipment Controller BACnet™ MS-TP®
communication adapter
o VCM7607V5000E, Terminal Equipment Controller Echelon™
LonTalk® communication adapter
o VCM7000V5000W Terminal Equipment Controller wireless Zigbee™
communication adapter
T
ERMINAL
, I
DENTIFICATION AND
F
UNCTION
Wiring
Part Number VT7657B5x00(X) VT7607B5x00(X)
Schedule Yes No
Top left terminal block
Y2 X X
Y1 X X
G X X
RC X X
C X X
Top right terminal block
RH X X
W1 X X
W2 X X
Bottom terminal block
HUM X X
AUX X X
DEHUM X X
DI X X
HS X X
SCOM X X
OS X X
HL X X
