18 | PIR Ready VT76x7 Series-Installation Guide
Monday timer
Schedule set
Tuesday timer
Schedule set
Wednesday timer
Schedule set
Other days are
identical
Monday
set? Y/N
No next

Yes down

Tuesday
set? Y/N
No next

Yes down

Wednesda
set? Y/N
No next

Yes down

Selects the day to be scheduled or
modified
Yes key to access day scheduling, No key to jump to next day
Occupied
Day? Y/N
No next

Yes down

Occupied
Day? Y/N
No next

Yes down

Occupied
Day? Y/N
No next

Yes down

Yes = Daily schedules will be
accessed
No = Unoccupied mode all day
Yes key to access day scheduling, No key to jump to next day
Copy Y/N
Previous
Yes next

No down

Copy Y/N
Previous
Yes next

No down

Yes = Will copy previous day
schedule
No = Daily schedules will be
accessed
Yes key to copy previous day, No key to set new time value for each day
Occupied
00:00 AM
Use ▲▼
To set
value
Occupied
00:00 AM
Use ▲▼
To set
value
Occupied
00:00 AM
Use ▲▼
To set
value
Sets Event # 1 Occupied time
Will activate occupied setpoints
Use ▲▼ to set value, Yes key to confirm
Unoccup
00:00 AM
Use ▲▼
To set
value
Unoccup
00:00 AM
Use ▲▼
To set
value
Unoccup
00:00 AM
Use ▲▼
To set
value
Sets Event # 2 Unoccupied time
Will activate unoccupied setpoints
Use ▲▼ to set value, Yes key to confirm
Typical examples of a 2 event office schedule
Ex. #1 Office building closed all weekend
Event Period #1 - Event #1 Period #1 - Event #2
Occupied Unoccupied
Setpoint
Cool Heat Cool Heat Daily
72 °F 70 °F 80 °F 62 °F Occupancy
Monday 7.00 AM 6.00 PM Day time only
Tuesday 7.00 AM 6.00 PM Day time only
Wednesday 7.00 AM 6.00 PM Day time only
Thursday 7.00 AM 6.00 PM Day time only
Friday 7.00 AM 6.00 PM Day time only
Saturday 12.00 PM * 12.00 PM * Unoccupied
Sunday 12.00 PM * 12.00 PM * Unoccupied
* Scheduling consecutive events to the same time will cause the Terminal Equipment
Controller to choose the last event as the time at which it will set its schedule. In the
above example, the Terminal Equipment Controller will control to the unoccupied set
point until 7:00 AM Monday.
Ex. #2 Commercial building which is occupied all weekend
Event Period #1 - Event
#1
Period #1 - Event
#2
Occupied Unoccupied
Setpoint
Cool Heat Cool Heat Daily
72 °F 70 °F 80 °F 62 °F Occupancy
Monday 8.00 AM 5.00 PM Day time only
Tuesday 8.00 AM 5.00 PM Day time only
Wednesday 8.00 AM 5.00 PM Day time only
Thursday 8.00 AM 5.00 PM Day time only
Friday 8.00 AM 5.00 PM Day time only
Saturday 12.00 AM ** 11.59 PM ** Occupied
Sunday 12.00 AM ** 11.59 PM ** Occupied
Note: 12:00 PM = Noon
12:00 AM = Midnight
