20 | PIR Ready VT76x7 Series-Installation Guide
* Scheduling events to the same time will cancel the last period and leave the Terminal
Equipment Controller in unoccupied mode
Ex. #2 Residential
Event Period 1 -
Event 1
Period 1 -
Event 2
Period 2 -
Event 3
Period 2 -
Event 4
Setpoint Occupied Unoccupied Occupied Unoccupied
Cool Heat Cool Heat Cool Heat Cool Heat Daily
72
°F
70
°F
80
°F
62
°F
72
°F
70 °F 80
°F
62 °F Occupancy
Monday 6:00 AM 8:00 AM 4:00 PM 10:00 PM Day/evening
time only
Tuesday 6:00 AM 8:00 AM 4:00 PM 10:00 PM Day/evening
time only
Wednesday 6:00 AM 8:00 AM 4:00 PM 10:00 PM Day/evening
time only
Thursday 6:00 AM 8:00 AM 4:00 PM 10:00 PM Day/evening
time only
Friday 6:00 AM 8:00 AM 4:00 PM 11:30 PM Day/evening
time only
Saturday 8:00 AM * 8:00 AM * 8:00 AM * 11:59 PM * Day time only
Sunday 12:00 AM * 12:00 AM * 12:00 AM * 11:59 PM * Occupied all
day
* Scheduling consecutive events to the same time will cause the Terminal Equipment
Controller to choose the last event as the time at which it will set its schedule. In the above
example for Saturday, the Terminal Equipment Controller will control to the occupied set
point from 8:00 AM until 11:59 PM. Since it is desired to be in occupied mode throughout
the night, then it is necessary to schedule the first event on Sunday at 12:00 AM. The
Terminal Equipment Controller will force a one minute unoccupied period for a one minute
period (between 11:59 PM and 12:00 AM on Saturday)
I) Clock/Day Settings
Clock
set Y/N
This section of the menu permits the user to set the time and day.
Time setting Day setting Time format setting
Time
set? Y/N
No next

Yes down

Day
set? Y/N
No next

Yes down

12/24hrs
set? Y/N
No = exit
Yes down

Time
0:00
Use ▲▼
To set value Day
Monday
Use ▲▼
To set value 12/24hrs
12 hrs
Use ▲▼
To set value
J) Schedule hold
Schedule
hold Y/N

This menu will only appear on stand-alone (Network Ready) Terminal
Equipment Controller, i.e. without a
BACnet™ / Echelon™ module.

This section of the menu permits the user to set a permanent schedule
hold, which bypasses the internal Terminal Equipment Controller
scheduling.

The permanent schedule hold function is typically used for non-
scheduled events that extend for various periods of time.
