30 | PIR Ready VT76x7 Series-Installation Guide

RH LT

Reset RH lower outside

temperature setpoint

Default value = -20°F

(-29°C)

Minimum outside air temperature for RH setpoint reset.

Only valid if an outdoor air sensor is connected at the

Terminal Equipment Controller or a network value is

transmitted to the Terminal Equipment Controller. See RH HT

& RE Sp.

From

–40°F up to 15°F (-40°C to –9.5°C)

Aux cont
Auxiliary contact
configuration

Default value = N.O.
normally open

This contact can be used to energize peripheral devices such
as: lighting equipment, exhaust fans, economizers, etc.
This contact will operate in parallel with the internal
occupied/unoccupied schedule of the Terminal Equipment
Controller or the remote NSB contact if DI1 or DI2 is used.
When the system is in OFF mode, the contact will remain in
its unoccupied status independently of the occupied /
unoccupied schedule.

Configured

Contact

occupied status

Contact

unoccupied status

N.O.

Closed

Opened

N.C.

opened

Closed


Prog rec
Progressive recovery
enabled

Default value = Off

Progressive recovery is
automatically disabled if DI
1 and / or DI 2 are
configured remote NSB

For scheduling model
only - VT7657B1000B

Off, = no progressive recovery
The occupied schedule time is the time at which the system
will restart.

On, = progressive recovery active.
The occupied schedule time is the time at which the desired
occupied temperature will be attained. The Terminal
Equipment Controller will automatically optimize the
equipment start time.

In any case, the latest a system will restart is 10 minutes prior
to the occupied period time.
