10009383 49
XDV Direct Vent Gas Fireplace
33XDV/36XDV/39XDV
(continued)
Ref. Description 33XDV 36XDV 39XDV
33a. Orifice Pilot Nat. RF -- 20000908 n/a
33b. Orifice Pilot LP RF -- 20000907 n/a
34a. Pilot Assembly Nat. RF -- 20002266 n/a
34b. Pilot Assembly LP RF -- 20002268 n/a
35. Thermopile (RF) -- 20002400 n/a
36. Pilot Tubing w/Fittings PSE -- 10003279 n/a
37. Ignitor Piezo Honeywell -- 20000062 n/a
38. Valve SIT 820.662 (RN) 20010563 20010563 20010563
39. Valve SIT EN 20011013 20011013 20011013
40. Valve HW RFN Conv RV8310E -- 20003719 n/a
41. Flexible Gas Line w/ON/OFF Shut-off 20002500 20002500 20002500
42. Manifold Tubing w/fittings (not shown) 57318 57318 57318
43. Fan Kit Assembly FK24 (Optional, not shown) ZA1100 ZA1100 ZA1100
44. Fan Kit Assembly FK12 (Optional, not shown) ZA1110 ZA1110 ZA1110
45. Fan w/Bracket 54103 54103 n/a
46. Electrical Cord (6ft) Fan Kits 51865 51865 51865
47. Fan Temperature Sensor (FK24) 51704 51704 51704
48. Speed Control (FK24) 51738 51738 51738
49. Speed Control Knob (FK24) 51882 51882 51882
50. Remote Switch Wire Assembly 20010345 20010345 20010345
51. Gasket Plate Air Inlet 10008179 10007706 10007706
52. Gasket Plate Cover Flue Products 10002233 10002233 10002233
53. Gasket Plate Cover Flue Pipe 10002237 10002237 10002237
54. Gasket Burner Base 10007387 10007087 10007980
55. Relief Plate Assembly (Burner Base) 10004192 10004192 10004192
56. Relief Plate Assembly 10007396 10002429 10007967
57a. Console Assembly RN/RP 10009153 10009153 10009153
57b. Console Assembly RF -- 10009377 n/a
58. Valve ON/OFF 10009138 10009138 10009138
59. Transmitter -- 20002047 n/a
60. Cord Set RF Valve -- 20002541 n/a
61. Antennae HW395783-1 RFN/RFP Valve -- 20003561 n/a
62. Shield Heat Pilot 10000248 10000248 10000248
63. Ignition Control Synetek (EN) 10007939 10007939 10007939
64. Wire Harness (EN) Synetek (low voltage) 10008139 10008139 10008139
65. Wire Harness (EN) Synetek 10008140 10008140 10008140
66. Electrical Cord (6ft) Ignition Control 10008298 10008298 10008298
67. Clevis Pin 10008615 10008615 10008615
68. Clip Pin Hitch 10008616 10008616 10008616
69. Wire w/Terminals Assembly 10009179 10009179 10009179
70. Knob Valve ON/OFF 76525 76525 76525
71. Shield Pilot Front 10009404 10009154 --
Fuel Conversion Kits
Conversion Kit, NG to LP
33XDV KIt # 10009427
36XDVRN/EN Kit # 10009419
36XDVRFN Kit # 10008276
39XDVRN Kit # 20011505
39XDVEN Kit # 20011504
Conversion Kit, LP to NG
33XDV Kit # 10009429
36XDVRP/EP Kit # 10009421
36XDVRFP Kit # 10008277
39XDVRP Kit # 20011506
