XDV Direct Vent Gas Fireplace
48 10009383
33XDV/36XDV/39XDV
(continued)
Ref. Description 33XDV 36XDV 39XDV
1. Log Set (Complete) 10009399 10009367 20010991
1a. Log Rear 10009392 (A49) 10009361 (B152) 20010994
1b. Log Center Right 10009394 (A51) 10009362 (B153) --
1c. Log Right Top 10009395 (A52) 10009363 (B154) 20010995
1d. Log Front 10009393 (A50) 10009364 (B155) --
1e. Log Cross Over Center 10009396 (A53) 10009365 (B156) --
1f. Log Left Top 10009397 (A54) 10009366 (B157) --
1g. Log Top Center -- -- 20010677
1h. Log Front Right -- -- 20011514
1i. Log Front Left -- -- 20010996
1j. Log Overlay -- -- 20010674
2. Volcanic Lava Rock (1lb pkg) 10001454 10001454 20000376
3. Embers Package 51915 51915 0005219
4. Bracket Rear Log Assembly Black 10009403 10008856 20011363
5. Grate Assembly Black 10008831 10008831 20010490
6a. Burner Housing Assembly - NG -- -- 20011347
6b. Burner Housing Assembly - LP -- -- 20011528
6c. Burner Housing Assembly - NG 10009163 10008864 --
6d. Burner Housing Assembly - LP 10009744 10010125 --
7. Brkt Support Center Log Assembly 10009024 10009024 --
8. Angle Front Log Support Assembly 10009386 10009142 --
9. Bi-metal Air Shutter Assembly 10009140 10009140 --
9a. Bi-metal Air Shutter Assembly (NG) -- -- 20011350
9b. Bi-metal Air Shutter Assembly (LP) -- -- 20010666
10. Ceramic Tile 57803 57803 57803
11. Burner Tube Assembly 10009168 10009157 20010580
12. Window Assy w/ Glass 10009483 10007490 10007971
13. Clamp Frame Window 54174 54174 54174
14. Louvre Assembly Top 10007400 10007090 10007984
15. Louvre Assembly Bottom 10007397 10007092 10007986
16. Bracket Burner Tube 10009146 10009155 --
17a. Orifice Rear Burner - Nat. Refer to Rating Plate for Orifice Size
17b. Orifice Rear Burner - LP Refer to Rating Plate for Orifice Size
18a. Orifice Front Burner - Nat. Refer to Rating Plate for Orifice Size
18b. Orifice Front Burner - LP Refer to Rating Plate for Orifice Size
19. Switch Rocker 53606 53606 53606
20. Remote Switch Kit (not shown) 20010793 20010793 20010793
21a. Orifice Pilot - Nat. 10002268 10002268 10002268
21b. Orifice Pilot - LP 10002269 10002269 10002269
22a. Pilot Assembly SIT (RN) 10002264 10002264 10002264
22b. Pilot Assembly SIT (RP) 10002265 10002265 10002265
23a. Pilot Assembly SIT (EN) 10002387 10002387 10002387
23b. Pilot Assembly SIT (EP) 10002388 10002388 10002388
24. Pilot Tubing w/Fittings SIT 10001296 10001296 10001296
25. Pilot Hood 10002385 10002385 10002385
26. Thermocouple (RN/RP) 53373 53373 53373
27. Thermopile (RN/RP) 51827 51827 51827
28. Electrode Ignitor w/Cable (RN/RP) 10001297 10001297 10001297
29. Electrode Ignitor (EN/EP) 52465 52465 52465
30. Cable Ignitor (EN/EP) 10000696 10000696 10000696
31. Sensing Electrode (EN/EP) 57885 57885 57885
32. Ignitor Piezo w/Nut SIT 50932 50932 50932
