Vermont Casting 36XDV User Manual
Page 23
10009383
23
XDV Direct Vent Gas Fireplace
FP1184
Typical roof/ceiling
support apps.
Typical Roof
Support
Application
Typical Ceiling
Support
Application
Fig. 44 Venting supports.
FP1184
Min.
2' (610 mm)
FP1185
Fig. 45 Minimum termination to roof clearance.
TWL101a
Twist Lock Pipe
2/8/99 djt
3 #5 Sheet Metal
Screws per Joint
Sealant
TWL101a
Fig. 46 Roof flashing.
Storm Collar
