50
11. SPECIFICATIONS
11.1. TS-780 Central Unit
Power Source 220 – 240 V AC, 50/60 Hz
Power Consumption 60 W
Rated Output 36 V DC, 650 mA x 2
Input MIC: –60 dB*, 600 Ω, unbalanced, phone jack
AUX: –20 dB*, 10 kΩ, unbalanced, phone jack
Output Recording: –20 dB*, 10 kΩ, unbalanced, phone jack, pin jack x 2
Headphones: Mini jack
Equalizer Insertion
Input Terminals
Input: 0 dB*, 10 kΩ, pin jack
Output: 0 dB*, 10 kΩ, pin jack
Expansion Input and
Output Terminal
Input: 0 dB*, 10 kΩ, unbalanced, pin jack x 2
Output: 0 dB*, 10 kΩ, unbalanced, pin jack x 2
Control: 10 kΩ or more, voltage output, pin jack x 2
Control Priority speech chime: Operation of TS-781's priority key activates a
single-tone chime.
Speaker restriction: Number of simultaneously-usable TS-782s can be
set to 0 − 4.
Automatic Mic-off Function: OFF, 30 s (selectable)
Feedback Suppressor function (FBS): EXT, OFF, AUTO, MANUAL mode (selectable)
MP3 recording and playback
Operating Temperature 0 to 40°C
Operating Humidity 90 % RH or less (no condensation)
Finish Panel: Aluminum, black, 30% gloss, paint
Case: Steel plate, black, 30% gloss, paint
Dimensions 420 (w) x 96.1 (h) x 226.2 (d) mm
Weight 3 kg
* 0 dB = 1 V
Note: The design and specifications are subject to change without notice for improvement.
• Accessory
Power cord (2 m) ....................................... 1
• Optional products
Extension cord: YR-780-2M, YR-780-10M
Rack mounting bracket: MB-23B
MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson.
Supply of this product does not convey a license nor imply any right to distribute MPEG Layer-3 compliant
content created with this product in revenue-generating broadcast systems (terrestrial, satellite, cable and/or
other distribution channels), streaming applications (via Internet, intranets and/or other networks), other content
distribution systems (pay-audio or audio-ondemand applications and the like) or on physical media (compact
discs, digital versatile discs, semiconductor chips, hard drives, memory cards and the like).
An independent license for such use is required. For details, please visit http://mp3licensing.com.
