Toa TS-780 Series User Manual
Page 13
13
5.4.2. Using an external graphic equalizer
Step 1. Connect an external equalizer to the unit as shown below.
Step 2. Set the Feedback suppressor switch to the EXT position.
Step 3. Take measures against acoustic feedback using the graphic equalizer.
For operation method of the graphic equalizer, read the instruction manual supplied with it.
TS-780 Central unit
Equalizer
IN
OUT
OFF
AUTO
EXT
MANUAL
