Fieldware ® Link 4.02
INTERFACE OVERVIEW
The menus allow you to have access to all functions. Most of the menu functions can be accomplished with a click of the toolbar or right-click on
the catalog.
The toolbar allows you to have one-click access to many common functions. Hover over any button to view button information. All toolbar button
functionality can be duplicated in one of the drop down menus. Most can be duplicated in the catalog tree view right-click options.
The catalog tree view allows you to observe the organization of Machine Settings, Clients, Farms, Fields and Jobs within the catalog. Within a
catalog, you can add new Machine Settings, Clients, Farms, Fields or Jobs; and copy, delete and organize existing Machine Settings, Clients,
Farms, Fields or Jobs. Most catalog tree view functionality can be accessed in one of the drop down menus or on the toolbar.
Machine Settings, Clients, Farms, Fields and Jobs are each given their own tab when opened. The screen can be organized to see multiple tabs
at one time.
Figure 6: Interface Overview
Inactive Tabs
Catalog
Toolbar
Menu
Tab List Active Tab
Close Active Tab
