26
www.teejet.com
Fieldware
®
Link 4.02
IMPORTING/EXPORTING
Profiles for Jobs and Machine Settings can be imported from or
exported to a USB drive for use with the Matrix Pro or Matrix Pro GS.
See the Matrix Pro or Matrix Pro GS user manual specific to the
console software version for details on importing and exporting (called
transfer) on the console.
To access the Port Profiles tab:
1. Click PORT PROFILES toolbar option or menu option.
2. Select the console model.
►Matrix Pro 570/840 v2.xx - Includes both Matrix Pro and Matrix
Pro GS consoles running software version 2.xx. Machine
Settings are unsupported and will not be included in a port.
►Matrix Pro 570/840 v3.xx - Includes only Matrix Pro GS consoles
running software version 3.xx. All settings are supported in
software version 3.0x and above.
3. Select the USB drive.
4. Click
OK
.
Figure 59: Import/Export
Toolbar Option Menu Option
Exporting profiles to the console
NOTE: Exporting a Job profile or a Client/Farm/Field profile containing
a Job profile to a USB drive will remove the Job from the
catalog.
To include a selected profile to be worked with on the Matrix Pro or
Matrix Pro GS:
1. Access the Port profiles tab.
2. On the catalog, highlight the profiles to be exported.
◄The Machine Settings profile, to copy a specific profile
◄The Job, to move a specific Job.
◄The Field, to move all Jobs associated with the selected Field.
◄The Farm, to move all Jobs associated with the selected Farm.
◄The Client, to move all Jobs associated with the selected Client.
3. Click EXPORT PROFILE button or click and drag to the import/
export tab.
4. Repeat steps 1 to 2 as needed for other profiles.
5. Click
DONE
.
6. Remove USB drive.
7. Insert USB drive into Matrix Pro or Matrix Pro GS.
8. Follow instructions for the specific console software version.
Figure 60: Exporting Profiles to the Console
Export Profile
Import/Export Tab
