UniPilot
®
PREPaRation
Before beginning the installation, thoroughly clean the steering wheel and steering column area.
Park the vehicle on a clean, level floor with adequate clearance to work around.
Do not attempt to loosen or attach any fittings while the engine is running.
Photos and illustrations may vary from the actual components provided. This may be due to different installation options, operation modes or
production models.
Always try to use original parts. Built to the highest standards of safety and reliability, TeeJet Technologies parts are to be used for this system as
others might jeopardize the safety and function of the system. TeeJet is not responsible for any redesign or adaptations of the UniPilot ESM. Any
changes to the UniPilot ESM voids the company warranty. TeeJet Technologies supplies a set of mounting brackets that combined can create a
variation of options for your specific vehicle. Not all vehicles have been addressed with these parts and modifications or additions to these parts
may be needed to fit your specific vehicle.
Safety Information
TeeJet Technologies is not responsible for damage or physical harm caused by failure to adhere to the following safety requirements.
As the operator of the vehicle, you are responsible for its safe operation.
The UniPilot is not designed to replace the vehicle's operator.
Do not leave a vehicle while the UniPilot is engaged.
Be sure that the area around the vehicle is clear of people and obstacles before and during engagement.
The UniPilot is designed to support and improve efficiency while working in the field. The driver has full responsibility for the quality and work
related results.
Disengage and put the UniPilot ESM (Electric Steering Motor) in the standby position before operating on public roads. Put the UniPilot ESM in
the standby position when not in use to prevent accidental engagement or loss of vehicle control.
CoMPonEnts
Unpack the installation kit and identify the required parts for your installation. Soome kits may not include all items listed.
Part Number Description Quantity
32-04040 Switch, Engage/Disengage FieldPilot .....................................................................................................................................1
32-04057 Switch, System Ready, UniPilot ..............................................................................................................................................1
45-05381 Cable, 3 Pos. Battery 12'/3.66 m w/15 Amp Fuses ......................................................1
45-05626 Cable, Power/CAN/RS232 Adapter to Conxall 8pg ................................................................................................................1
45-07718 Harness, SCM Short ...............................................................................................................................................................1
45-07727 Cable, SCM to UniPilot Electric Steering Motor (ESM) ..........................................................................................................1
45-08101 Terminator, CAN Male, WP as Shipped ..................................................................................................................................1
78-08075 Steering Control Module (SCM), Pro ......................................................................................................................................1
90-02806 Kit, UniPilot Assisted Steering System ...................................................................................................................................1
28-01029 UniPilot Electric Steering Motor (ESM) (included in 90-02806 Kit) ........................................................................................1
28-01030 UniPilot Contact Wheel (included in 90-02806 Kit) ................................................................................................................1
91-07015 Kit, UniPilot Universal Mounting Bracket (included in 90-02806 Kit) ......................................................................................1
90-50013 Kit, Cable Tie Bundle (15) .......................................................................................................................................................1
98-05284 Manual, Installation, UniPilot ..................................................................................................................................................1
