TeeJet UniPilot User Manual
Page 20
U n i P i l o t
i n s t a l l a t i o n M a n U a l
1801 Business Park Drive
Springfield, Illinois 62703 USA
Tel: (800) 643-8324 • Fax: (800) 230-6211
www.teejet.com
®
six simple steps to Get Going!
1. Assemble Universal Mounting Bracket Kit on steering column so that it can be
adjusted with the installation of the UniPilot ESM.
2. Install UniPilot ESM and check spacing.
• Attach the UniPilot ESM to the mounting bracket. The steering wheel should rotate
freely around when the UniPilot ESM is in the Operating Position. When in the
Standby Position, there should be 1.6 in. / 40 mm of space between the UniPilot
contact wheel and the vehicle's steering wheel.
3. Secure or firmly tighten the mounting parts to Steering Column.
4. Connect Electronics.
5. Program Specific Settings on Guidance Console.
6. Activate & GO!
98-05226-ENUS R4 English/US
© TeeJet Technologies 2013
Standby Position
Operating Position
1.6 in. / 40 mm of space
