CenterLine
Software Version 2.00
CenterLine 25
CenterLine Setup
Lightbar Setup
Lightbar setup allows the selection of several parameters related to the lightbar. There are five
lightbar settings: Drive Sensitivity , Display Mode , two selectable mes-
sages: and , and (See Figure 30 and Table 8).
Spacing
The Spacing setting allows the selection of the distance that a single light on the lightbar LEDs rep-
resents.
To change the Spacing setting, go to Lightbar setup, scroll until is displayed in the
text window, and press Enter. To increase the spacing distance press UP; to decrease the spacing
press Down. Press the Enter key when the desired spacing is set. The Spacing range is 0.5 ft. to
9.5 ft., in 0.5’ increments.
Figure 30: The Lightbar Setup Flow
Setting Name Default Value
Change at 1st
Time Start up
Spacing 1.5 ft. Optional
Mode Swath Optional
Text 1 X-Track Error Optional
Text 2 Applied Area Optional
Steer bar? No Optional
Table 8: Lightbar Menu Item Default Settings
