JOB PARAMETERS
Job Parameters configures application settings. Options include Active Trip Counter, Application Rate, Tonnage,
Gate Height and Density.
MAIN SETUP MODE MENU STRUCTURE
| | | | | |
Counters Job Parameters Machine User Interface Communication Help
Figure 3-13: Job Parameters
Figure 3-14: Tonnage On
1. From the Main Setup Screen , select JOB
PARAMETERS.
NOTE: Settings are NOT automatically saved when
selected. The ACCEPT KEY must be selected
to save the setting. Select the ESCAPE KEY
to escape without saving settings and return to the
previous menu.
Active Trip Counter
Active Trip Counter selects one of up to ten (10) active trip
counters to view the desired trip information. The trip that
is “active” is displayed/active on the Operation Screen.
• To select the Active Trip Counter, use the number
pad or slide bar.
NOTE: The selected trip counter will have all data
modified (added too) when additional operations
are activated. If current trip counter is not cleared,
the new data will be added to the existing data.
Application Rate
Application Rate defines a target rate of product being
applied per hectare/acre. This setting will set the same
for all active trips. Range is 0 - 9999 lb/ac / 0 - 9999 kg/
ha.
• To select the Application Rate, use the number pad
or slide bar.
