RED MOTION MOUNT OPERATION GUIDE
COPYRIGHT © 2014 RED.COM, INC
955-0013, REV-E | 29
NEUTRAL DENSITY AND SHUTTER ANGLES
SPECIFICATION
DESCRIPTION
Soft/Square Shutter Max Frame Rate
1
109.98 FPS
Soft/Square Shutter Optical Density Range
0.48 to 1.20 (1.60 to 4.00 stops)
Square (Global) Shutter Angle Range
2
62.1° to 180°
Soft Shutter Angle Range
2
62.1° to 194.4°
ND Only Optical Density Range
0.48 to 2.40 (1.60 to 8.00 stops)
ND Only Angle Range
1° to 360°
1. DSMC firmware versions prior to v5.2.14 DO NOT limit maximum frame rate. RED recommends using a maximum frame rate of 109.98
with a MOTION MOUNT. Selecting frame rates higher than 109.98 FPS, may result in double exposures.
2. Values are based on DSMC firmware v5.2.28. Values outside of provided ranges are allowed in firmware versions earlier than v5.2.14.
Frame rate settings outside of the supported range may result in a double exposures.
MAXIMUM FRAME RATES
When the Soft or Square shutters are enabled, the maximum frame rate (FPS) is limited to ensure that the
DSMC and MOTION MOUNT capture the highest quality image without exposure issues.
RESOLUTION
EPIC DRAGON
SCARLET DRAGON
EPIC MYSTERIUM-X
SCARLET MYSTERIUM-X
6K FF
51.92
12.08
–
–
6K 2:1
52.79
12.08
–
–
6K WS
58.42
12.08
–
–
6K HD
52.16
12.08
–
–
5K FF
56.95
48.73
56.71
12
5K 2:1
58.73
51.40
58.42
12
5K WS
64.49
60.92
64.61
12
5K HD
56.95
48.73
56.71
12
4K FF
64.68
60.92
64.61
30
4K 2:1
66.51
64.25
–
–
4K WS
72.36
72.36
72.68
36
4K HD
64.68
60.92
64.61
30
3K FF
74.49
74.49
74.32
48
3K 2:1
76.30
76.30
–
–
3K WS
82.01
81.01
82.11
60
3K HD
74.49
74.49
74.32
48
2K FF
88.05
88.05
87.93
60
2K 2:1
89.73
89.73
–
–
2K WS
95.05
95.05
95.11
75
2K HD
88.05
88.05
87.93
60
NOTE: Maximum frame rates are based on DSMC firmware v5.2.28. Values may vary slightly based on the DSMC
firmware version.
