RED MOTION MOUNT OPERATION GUIDE
955-0013, REV-E | 22
SQUARE SHUTTER: STROBE SAFE OPERATION
The table below provides recommended maximum shutter angles for recording strobe lights using the Square
shutter.
FRAME RA
TE
RESOLUTION
1K 2K 3K 4K 5K 6K
1 180° 180° 180° 180° 180° 180°
2 180° 180° 180° 180° 180° 180°
4 180° 180° 180° 180° 180° 180°
8 180° 180° 180° 180° 180° 180°
12 180° 180° 180° 180° 180° 180°
16 180° 180° 180° 180° 180° 180°
24 180° 180° 180° 180° 180° 171°
25 180° 180° 180° 180° 179° 169°
30 180° 180° 180° 180° 167° 154°
40 180° 180° 180° 162° 142° 126°
48 180° 180° 172° 147° 123° 103°
50 180° 180° 169° 143° 118° 97°
60 180° 180° 155° 123° 93° 69°
72 180° 174° 138° 100° 64° None
75 180° 172° 134° 94° None None
90 180° 158° 113° 65° None None
96 180° 152° 105° None None None
100 179° 149° 99° None None None
120 167° 131° 71° None None None
CAUTION: Firmware versions earlier than v5.2.14 allow values outside of these ranges. Settings outside of the
supported range will result in a double exposure of the frame.
