RED MOTION MOUNT OPERATION GUIDE
COPYRIGHT © 2014 RED.COM, INC
955-0013, REV-E | 13
NEUTRAL DENSITY (ND) RANGE
The table below provides the available fraction values, optical density values, and stop losses. The values
provided are in increments of 1/2 and 1/3 stops.
The available ND range is based on the currently selected shutter type.
ND Only: The available optical density range for “ND Only” is 0.48 to 2.40 (1.60 to 8.00 stops).
Soft: The available optical density range for “Soft” is 0.48 to 1.20 (1.60 to 4.00 stops).
Square: The available optical density range for “Square” is 0.48 to 1.20 (1.60 to 4.00 stops).
ND VALUES
SHUTTER TYPES
FRACTION
DENSITY
STOPS
ND ONLY
SOFT/SQUARE
1/3.03
0.48
1.60
√
√
1/3.18
0.50
1.67
√
√
1/4.00
0.60
2.00
√
√
1/5.06
0.70
2.34
√
√
1/5.66
0.75
2.50
√
√
1/6.36
0.80
2.67
√
√
1/8.00
0.90
3.00
√
√
1/10.13
1.01
3.34
√
√
1/11.31
1.05
3.50
√
√
1/12.73
1.10
3.67
√
√
1/16.00
1.20
4.00
√
√
1/20.25
1.31
4.34
√
X
1/22.63
1.35
4.50
√
X
1/25.46
1.41
4.67
√
X
1/32.00
1.51
5.00
√
X
1/40.50
1.61
5.34
√
X
1/45.25
1.66
5.50
√
X
1/50.91
1.71
5.67
√
X
1/64.00
1.81
6.00
√
X
1/81.01
1.91
6.34
√
X
1/90.51
1.96
6.50
√
X
1/101.83
2.01
6.67
√
X
1/128.00
2.11
7.00
√
X
1/162.02
2.21
7.34
√
X
1/181.02
2.26
7.50
√
X
1/203.66
2.31
7.67
√
X
1/256.00
2.40
8.00
√
X
