RED MOTION MOUNT OPERATION GUIDE
955-0013, REV-E | 28
RED MOTION MOUNT TI PL
SPECIFICATION DESCRIPTION
Dimensions Height: 3.23 in. (82.0 mm)
Width: 3.23 in. (82.0 mm)
Depth: 1.43 in. (36.2 mm)
Weight 11.2 oz (318 g), Mount Only
Material Machined titanium
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature –20°C to 60°C (–4°F to 140°F)
Maximum Altitude 20,000 ft
Humidity Range 0 to 90% RH
Shock 10 g
Input Voltage +5.0 V DC
Power Consumption 1.5 W
RED MOTION MOUNT TI CANON
SPECIFICATION DESCRIPTION
Dimensions Height: 3.14 in. (79.9 mm)
Width: 3.35 in. (85.0 mm)
Depth: 0.92 in. (23.3 mm)
Weight 8.0 oz (227 g), Mount Only
Material Machined titanium
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature –20°C to 60°C (–4°F to 140°F)
Maximum Altitude 20,000 ft
Humidity Range 0 to 90% RH
Shock 10 g
Input Voltage +5.0 V DC
Power Consumption 1.5 W
A
TECHNICAL
SPECIFICATIONS
