234 MBOX ® MEDIA SERVER USER MANUAL
* The Page Curl transitions attempt to use files 021 and 022 in the RAID/Mbox/plugins/images/grayscale folder. If these files do
not exist, the transitions will not work properly. File 021 is a 1920 x 1080 50% gray, and file 022 is a 480 x 480 radial gradient.
Both files are saved as JPEGs.
** These elements require additional input files in order to obtain the desired result. Users will need to provide their own additional
files.
47 Split Right old image splits and slides to the right
48 Split L/R Center old image splits and slides left and right from the center
49 Split Down old image splits and slides down
50 Split Up old image splits and slides up
51 Split U/D Center old image splits and slides up/down from the center
52 Split XY old image splits slides out from center
53 Bar Swipe Right old image slides to right in strips
54 Bar Swipe Left old image slides to left in strips
55 Bar Swipe Up old image slides upward in strips
56 Bar Swipe Down old image slides downward in strips
57 Page Curl 1 * curls from the bottom-right corner of the image to the top-left corner.
58 Page Curl 2 * curls from the top-right corner of the image to the bottom-left corner.
101-110 Custom Hard Wipe 1-10 ** hard edge wipe generated from additional image file
111-120 Custom Soft Wipe 1-10 ** soft edge wipe generated from additional image file
255 Object Fade fade out on current object, fade in on new object
Object Transitions
ID Transition Description
0 Dissolve dissolve
1 Implode old object scales down to zero, then new object expands in its place
2 X/Y-axis zoom object moves out/in in x/y-plane, variable w/ Object XFade Angle
3 Z-axis zoom object moves out/in along z-axis
4 Impact new object knocks old object out in x/y-plane, variable w/ Object XFade Angle
5 Wheel objects change as if on gobo wheel, variable w/ Object XFade Angle
6 Loose Wheel as above, but mechanically unsound, variable w/ Object XFade Angle
7 Orbit new/old objects spin around each other, variable w/ Object XFade Angle
8 n/a
9 Newsflash 1 objects spin in/out both in same direction, variable spin w/ Object XFade Angle
10 Newsflash 2 as above but objects spin in opposite directions
Transitions (Continued)
ID Transition Description
