38
BAD BOY
®
SPOT LUMINAIRE FIELD SERVICE MANUAL
Figure 3-8: Accessing Zoom Lens Assembly
R2 / Designer Wheel
Head Cover
R1 Head Cover
Remove to Access Lenses
ZOOM LENS ASSEMBLY DETAIL
Lenses
8-32 x 3/8" PPB
Screw (2 ea)
CAUTION:
Hand tighten only. DO NOT use a
power tool on Head Cover screws.
