R EFERENCE T ABLES
0 2. 3 0 0 4. 0 3 00 . 5 4 123
A
DMX Mode 4
* When a DMX Power Pack is used, the first port channel controls the integral CD dimmer module for the VL5
and VL5B luminaires.
Table A-4: DMX512 Mode 4 (16-bit Extended)
Port
Number
DMX
Channel
VL5 / VL5B VL5Arc VL6 VLM
1 1 External
Dimmer*
Intensity Intensity Hi Byte Pan
2 Hi Byte Pan Hi Byte Pan Hi Byte Pan Lo Byte Pan
3 Lo Byte Pan Lo Byte Pan Lo Byte Pan Hi Byte Tilt
4 Hi Byte Tilt Hi Byte Tilt Hi Byte Tilt Lo Byte Tilt
5 Lo Byte Tilt Lo Byte Tilt Lo Byte Tilt Rotation Speed >
6 Blue Blue Wheel 1 Rotation Speed <
7 Amber Amber Wheel 2 --
8 Magenta Magenta Beam Iris --
9 Diffusion Diffusion Lens (Edge) --
10 Focus Time Focus Time Focus Time Focus Time
11 Color Time Color Time Color Time --
12 Beam Time Beam Time Beam Time --
13 Reset Reset Reset Reset
2 14-26 -- -- -- --
3 27-39 -- -- -- --
4 40-52 -- -- -- --
5 53-65 -- -- -- --
6 66-78 -- -- -- --
